• Model NO.：XE470C
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：46100kg
• Maximum Digging Height：10675mm
• Maximum Digging Depth：7337mm
• Max Digging Radius：10631mm
• Rated Speed：5.4,3.2km,H
• Color：Yellow
• Transport Package：Comply with Export Packaging Requirements
• Trademark：XCMG
• Origin：Jiangsu, China
• HS Code：84295212
• Production Capacity：10000,Year

  UnitParametersModelOperating weightkg46100Bucket capacitym³2.1-2.5EngineEngine model/Cummins QSM11Direct injection/√4×Strokes/√Water cooling/√Turbocharging/√A/A Air-air intercool/√Cylinders/6Output power of engineKw/rpm250/2000Max.torque/engineN.m/rpm1790/1400DisplacementL11Mian pertormanceTravel speedkm/h5.4/3.2Slewing speedr/min9Gradient capability°≤30°Ground pressurekPa82.7Digging capacity of tcuketkN284Digging capacity of tcuket rodkN236Max.tractionkN338Hydraulic systemMain pump/Tow plunger pumpsRated flow of main pumpL/min2×360Pressure of main safety valveMpa31.4/34.3Pressure of traveling systemMpa34.3Pressure of swing systemMpa28.4Pressure of pilot systemMpa3.9Oil volumeFuel tank capacityL650Hydraulic tank capacityL360Engine oil volumL38Apperance sizeA Total lengthmm12032B Total widthmm3580C Total heigthmm3842D Width of rotary tablemm2950E Length of trackmm5220F Total width of chassismm3580G Width of trackmm600H Wheelbase of trackmm4180I Track gaugemm2392/2890J Counterweight ground clearancemm1360K Min.ground clearancemm703(Tooth height not included)L Min.tail swing radiusmm3665Working scopeA Max.digging heightmm10675B Max.unloading heightmm7409C Max.digging depthmm7337D Digging depth at the range of 8feets horizontallymm7177E Max.vertical digging depthmm5225F Max.digging radiusmm11631G Max.swing heightmm4909Standard configurationBoom lengthmm7060Length of bucket rodmm2900Bucket capacitym³2.2Rock bucketOptional counfigurationBoom lengthmm7060Length of bucket rodmm3380/2500Bucket capacitym³2.1  2.3Rock bucket   2.5Earthmoving bucket
Company profile
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2015, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.
