35cbm/H Good performance Easy Installation Concrete Mixing Plant
FANGYUAN GROUP CO., LTD.- After-sales Service：Provided
- Warranty：Provided
- Type：Concrete Mixing Plant
- Productivity：35 Cubic Meters Per Hour
- Certification：ISO9001: 2000, CE
- Condition：New
Base Info
- Model NO.：HZS35
- Color：According to Customer′s Requirement
- Feeding Mode：Lifting Hopper
- Transport Package：Simple
- Trademark：FYG
- Origin：China
- HS Code：8474310000
- Production Capacity：2000sets ,Year
Description
1
Concrete Batcher
PLD1200-IIIBin 2m 3 3Pc Accuracy
± 2% Measure hopper 2000kg 1Pc measure Sensor XYL-1 1Pc Belt B500 4pc 2
Main body Concrete Mixer JS750 1set Accuracy
± 1% Cement measure system max. 400kg 1set Water measure system max. 200kg 1set Accuracy
± 1% Additive(liquid) measure system max. 40kg 1set Accuracy
± 1% Steel structure 1set Discharging 3.8m Lifting motor 1pc Lift orbit 1set Liftinghopper 1set 3
Water Supply System Water Tank 2.5m 3 1pc Water pump 3kW 1pc Control valve for water DF-50F 1pc pipeline 1set 4
Additives Supply System
Additive (liquid) tank 2.5m 3 1pc Pump BW6-16 1
set pipeline 1set Gas arch breaking preventing sedimentation 1set 5
Pneumatic System Pneumatic pump 1set pipeline 1set Additional parts 1set 6
Control System Control room 7m 2 1set controlling software HBK50 1set PLC CQM1H 1set
Relay MY2 1set Lap joint LC1-D 1set Aerotherapeutics GV2 1set Button XB2-BW 1set Control table 1set Printer LQ300 1pc Air -condition 1pc computer 1pc 7 Screw Conveyor LSY219-9 1set 8 Assembly Cement silo PSC100A
Discharging height 3.32m 1set
Concrete Batcher
PLD1200-III
± 2%
Main body
± 1%
± 1%
± 1%
Water Supply System
Additives Supply System
set
Pneumatic System
Control System
Relay
Discharging height 3.32m
