Gr180 190HP China Motor Grader with Hydraulic Pump for Sale
Shanghai Super-Above Industry Holdings Co., Ltd.- Condition：New
- Application：Railway, Mine, Farmland, Highway
Base Info
- Model NO.：GR180 motor grader
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
- Type：Medium-sized Grader
- After-Sales Service Provided：Overseas Service
- Drive Type：Rear-Axle Drive
- Engine Model：6ctaa8.3 D6114
- Rated Power/Speed：138kw,2200 140kw,2300rpm
- Dimension：8900X2625X3470mm
- Operating Weight：15400kg
- Max. Gradeability：20%
- Tire Inflation Pressure：260kpa
- Working Hydraulic Pressure：16MPa
- Transmission Pressure：1.3~1.8MPa
- Tractive Force：61.3kn
- Maximum Lift Above Ground：450mm
- Maximum Depth of Cutting：500mm
- Moldboard Width X Height：3048X610mm
- Blade Cutting Angle：28-70degree
- Transport Package：Naked in Container
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8429209000
- Production Capacity：5000PCS,Year
