China Factory New Strong (HQM388) with 2800kg Lift Capacity Backhoe Wheel Loader
Weifang Haiqin Top Machinery Co., Ltd.- After-sales Service：24 Hours Every Day of Technology and Parts Service
- Warranty：1 Year
- Certification：ISO, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic
Base Info
- Model NO.：HQM388
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
- Type：Medium-sized Loader
- Overall Size：6150×2250×3763
- Engine：Yuchai or Cummins
- Loading Lifting Capacity：2500kg
- Backhoe Capacity：0.3m3
- Max. Digging Depth：4082mm
- Min. Turning Radius：6581mm
- Transport Package：1 Unit in One Hq40 Container
- Specification：CE, ISO, SGS
- Trademark：Haiqin
- Origin：Shandong, China
- HS Code：84295100
- Production Capacity：8000 Units , Year
Description
The Main Performance Parameter of HQM388 Backhoe Loader
Overall Operating Weight 7800KG Final Reducer Single Stage Final Reducer Transport Dimension Rated Loader of Axle 4/18.5t mm L*W*H 6150×2250×3763 Transmission System Wheel base 2200mm Torque Converter Min. Ground Clearance 300mm Model YJ280 Bucket Capacity 1.0m3 Type Single-stage Three Elements Breakout Force 38KN Max. Efficiency 84.4% Loading Lifting Capacity 2500KG Inlet Pressure 0.4Mpa-0.55 Mpa Bucket Dumping Height 2742mm Outlet Pressure 1.2Mpa-1.5 Mpa Bucket Dumping Distance 1062mm Cooling Method Oil-cooling Pressure Circulation Digging Depth 52mm Gearbox Backhoe Capacity 0.3 m3 Type Fixed Shaft Power Transmission Max. Digging Depth 4082mm Oil Pressure of Clutch 1373Kpa-1569 Kpa Swing Angle of Excavator Grab 190o Gears Two Gears Ahead, Two Gears Astern Max. Pulling Force 39KN Max.Speed 22Km/h Engine Tyre Model YC4A105Z-T20 Model 14-17.5/19.5L-24 Type turbocharging four-stroke Pressure of Front wheel 0.22 Mpa Cylinder-Inside Diameter*Stroke 4-105 Pressure of Back Wheel 0.22 Mpa Rated Power 75KW/100HP Brake System Rated Speed 2400r/min Service Brake Air Over Oil Caliper Brake Min. Fuel Consumption 235g/kw.h External Type Max.Torque 310NM Self-regulation Displacement 4.3L Self-balance Steering System Emergency Brake Operation Power Implementing brake Model of Steering Device BZZ5-250 Manual Operation Power Terminating Brake Steering Angle ±36 o Hydraulic System Min. turning radius 6581mm Digging Power of Excavator Grab 46.5KN Pressure of the system 12Mpa Digging Power of Dipper 31KN Axle Bucket Lifting Time 5.4S Manufacturer Feicheng Axle Factory Bucket Lowering Time 3.1S Main Transmission Type Double Reduction Bucket Discharge Time 2.0S The parameters are subject to change without notice
