• Model NO.：LW500KN
• Type：Large Loader
• Bucket Capacity：3m3
• Dumping Height：3090
• Dumping Distance：1130
• Operating Weight：17200kg
• Wheelbase：3300
• Max. Traction：165kn
• Rated Power：162kw
• Max.Drawing Force  ：170kn
• Rated Power/Speed：162,2000kw,R,Min
• Emission：Euro II
• Transport Package：Comply with Export Packaging Requirements
• Specification：8185*3000*3465mm
• Trademark：XCM-G
• Origin：Xuzhou, Jiangsu
• HS Code：84295100

ItemParameterUnitRated load5tBucket capacity3m 3Dumping height3090mmDumping distance1130mmMax.drawing force  170kNMax. traction165kNDimension8185×3000×3465mmOperating weight17200kgBoom lifting time ≤6.0≤6.0Total time of three devices11sWheelbase3300sMin. turning radius (bucket outer)6910mmRated power162kWTravel speedI Gear (Forward/Backward)0-11.5/16.5                           km/hII Gear (Forward)0-38                                 km/hLong boom parameterItem Standard bucketCoal bucketBucket capacity2.7m³3.5Rated load4.5t4.0tDumping height3710mm3550mmDumping distance1180mm1300mmDimension8870×3000×33508870×3000×3465Attachment parameterAttachment parameter _ snow plowPushing snow width3800 mmHorizontal rotary angle±38 °Vibrating angle±6 °Obstacle crossing height0~150mm Rated power162KW Attachment parameter-clampDumping height3241 Dumping distance1902 Min. circle diameter  and max. opening  Basic model800×1990 IV  model430×2000 Attachment parameter-Sliding forkFork folding angle20 °Attachment length2053 mmAttachment width2516 mmAttachment height1200 mmFork teeth length1200mm Attachment parameter-Side dumpingBucket width3000mmDimension8310×3040×3465mmDumping height( straight/side ) dumping2960/4125mmDumping distance( straight/side ) dumping1272/105mmLifting height( straight/side ) dumping5407/6830mm

More modles for your reference:

LW500FN
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 16,500kg 36,376lb
Dimensions(L×W×H):
8,305mmX2,850mmX3,515mm
27'3''X9'4'''X11'6''

LW500K
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 17,200kg 37,919lb
Dimensions(L×W×H):
8,530mmX2,850mmX3,515mm
28'X9'4'''X11'6''

LW500K-LNG
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 17,600kg 38,801lb
Dimensions(L×W×H):
8,685mmX2,850mmX3,515mm
28'6''X9'4'''X11'6''

LW500KN
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 17,200kg 37,919lb
Dimensions(L×W×H):
8,530mmX2,850mmX3,515mm
28'X9'4'''X11'6''

ZL50G
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 17,500kg 38,580lb
Dimensions(L×W×H):
8,470mmX2,850mmX3,485mm
27'10''X9'4'''X11'5''

ZL50GN
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 17,500kg 38,580lb
Dimensions(L×W×H):
8,470mmX2,850mmX3,485mm
27'10''X9'4'''X11'5''

ZL50G-Super
Rated Power:
162kW 217HP @2,000rpm
Operating Weight: 17,500kg 38,580lb
Dimensions(L×W×H):
8,470mmX2,850mmX3,485mm
27'10''X9'4'''X11'5''
