New Model 700kg Mini Skid Steer Loader

XIAMEN LTMG CO., LTD.
  • Warranty：1 Years or 2000 Working Hours
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Rated Load：700kg
  • Transmission：Hydraulic Transmission
  • Load and Unload Mode：Front Discharge

Base Info

  • Model NO.：LT45
  • Walking Mode：Wheeled
  • Type：Skid Steer Loader
  • Product Name：New Model 700kg Mini Skid Steer Loader
  • Item：Mini Skid Steer Loader
  • Operating Weight：2780kg
  • Max.Dump Height：2266mm
  • Engine：Xinchai
  • Bucket Capacity：0.39m3
  • Rated Capacity：700kg
  • Skip Width：1720mm
  • Turn Radius：2056mm
  • Transport Package：Container
  • Specification：3535*1735*1979mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8429590000
  • Production Capacity：800sets,Year

Description

The specification of 700kg skid steer loaderItemDataItemDataMax working height(A)3490mmLoading capacity700KGMax pin height(B)3028mmWeight2860kgMax height on bucket level state(C)2814mmEngineDiesel engineMax dumping height (D)2266mmRated speed2500r/minMax Dumping distance(F)437mmType of engineFour cylinder, water-cooling, four-strokeWheel base(G)1044mmRated power45KWTotal height(H)1979mmFuel consumption rate on standard240g/KW·hGround clearance196mmFuel consumption rate on max torque238g/KW·hOverall length without bucket(K)2621mmNoise117dB(A)Total length(L)3400mmGenerator power500WSkip width(M)1720mmVoltage12VTotal width(W)1665mmStorage battery105AHTread width to center line (P)1425mmSpeed0-10 Km/hTire's thickness N)240mmDrive modeHydrostatic four-wheel driveDeparture angle(α)19°Tire10-16.5Bucket dump angle(β)41°Hydraulic pump flow for running110L/minRetracting angle(θ)18°Hydraulic pump flow for working50L/minTurn radius(R)2056mmSystem pressure15MP
