Eougem 2t Small Wheel Loader Price List Front End Loader
Shandong Oujin Engineering Machinery Co., Ltd.- Certification：ISO, CE
- Condition：New
- Rated Load：1-3t
- Transmission：Hydraulic - Mechanical
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：zl20
- Type：Small Loader
- Bucket Capacity：1cbm
- Rated Loading Weight：2000kg
- Engine Type：Yunnei,Cummins,Perkins
- Rated Power：76kw
- Operating Weight：5500kg
- Dumping Height：3400mm
- Dumping Reach：780mm
- Max Breakout Force：>58kn
- Max Traction：55kn
- Max Speed：30km,H
- Transport Package：2units Loaded in 1* 40 Hq
- Specification：5960*2010*2850
- Trademark：EOUGEM
- Origin：China Shandong
- HS Code：8429510000
- Production Capacity：3000sets in a Year
Description
Modelzl20 wheel loader
EngineModel WEICHAI engine Rated output(kw) 76KW Type In line,vertical,water cooled,four-stroke Number of cylinders 4 Method of starting Electric Lifting capacity(kg) 2000kg Bucket capacity 1m3 Lift height(mm) 2810mm Lift TIME(mm) 6.5s Operate weight (kg) 5500kg Axle-base(mm) 2430mm TIRE 16/70-20 Maximum speed 30km/hr Drive Mean Four Wheel drive Maximum gradeability 30 Torque converter model Yj280b dimension 5960*2010*2850mm
1.improve the steering pressure,steering easier and quick.
2.High reliability of the transmission system,adopting the xuzhou meritor drive axle,hangzhou gearbox.
3.Enhanced working device.
4.Enhanced transmission shaft.
5.Cycle time is short.
6.The pivotal point sealing dust.
7.The main parts quality assurance for a year.
Our advantage:
1.Different parts of the corresponding international plate, the vehicle parts do a tough steel is not easy to deform. Structural parts derusting surface adopts the advanced blast cleaning equipment, cleaning effect is obvious, the component will never rust.
2.Vehicle sheet metal parts using the international advanced 1.5-2.75 cold rolled plate production, the surface is smooth, not deformation.Sheet metal primer using electrophoretic method of paint, so that parts will never rust.
3.Use of copper composite, strong wear resistance. The pin shaft grinder using high frequency quenching processing, convenient installation, strong wear resistance.
4.By sheet metal forming, the driving cab hood has the features of high transparency, anticorrosion and the color won't wear out; with the international ultraviolet-proof all-steel cab of forming glass adopted, the driving cab is equipped with humanized adjustable seat, scuttle, making your vision broader and your driving safer; all those make the operation easy, natural and accurate, and relieve your fatigue as well.
5.Optimally designed by the computer, the bucket realizes huge spading force, with single dump cylinder and the "Z" shape turning structure.
6.Due to the overall frame stiffening, top and bottom hinge joint with knuckle bearing, there'll be convenient operation and less vibration; the frame is even more stable in harsh working environment, and the safety factor is greatly raised.
7.Fast action: it takes only 5 seconds to complete the "total cycle".
Why choose us?
1). The quality is guaranteed due to strong technical support ,high quality component ,advanced production line and strict quality control system.
2). One-stop service with a large spare parts warehouse and professional service team .No matter where you are, you are guaranteed of eougem warm reception, trustworthy and efficient professional services and persistent care.
