• Model NO.：SD22
• Rated Power：162kw,1800rpm
• Machine Weight：23400kg(Without The Scarifier)
• Blade Capacity：6.4m3 (Straight Tilt Blade)
• Blade Height(mm)：1315
• Transport Package：Packing Suit for Ocean Ship
• Specification：5750× 3725× 3395mm
• Trademark：Shantui
• Origin：Shandong, Jiangsu
• HS Code：8429119000

ITEMUNITSD22L×W×H (Ripper not included)mm5750×3725×3395Operating weight (Ripper not included)t23.4Engine-NT855-C280S10Rated powerkW/rpm162/1800Gradeability°30Blade type-Straight tilt blade U-blade
 Semi-U blade  Angle bladeBlade widthmmStraight tilt blade 3725×1315
U blade 3800×1343
Semi-U blade 3725×1374
Angle blade 4365×1055Dozing capacitym3Straight tilt blade 6.4
U blade 7.5
Semi-U blade 7.0
Angle blade 4.7Ma× drop below ground of blademm540Lift height of blademm1210Ripper type Single ripper   Three-shank ripperRipping depth of rippermmSingle ripper 695
Three-shank ripper 666Lifting height of rippermmSingle ripper515
Three-shank ripper 555Number of carriers (each side)-2Number of track rollers (each side)-6Number of track shoes (each side)-38Width of track shoemm560Track gaugemm2000Ground length and ground pressuremm/MPa2730-0.077Pitchmm216Forward speedkm/h0-3.60-6.50-11.2Reverse speed
km/h0-4.30-7.70-13.2
