• Model NO.：ZE210E
• Drive Type：Electric Drive
• Bucket Capacity：0.9cbm
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Mass：21300kg
• Swing Speed：11.5r,Min
• Maximum Drawbar Pull：192kn
• Bucket Digging Force(ISO)：147kn
• Arm Digging Force(ISO)：103kn
• Travel Speed (High / Low)：3.3,5.5km,H
• Engine Manufacturer：Cummins
• Rated Power：112,1950kw,Rpm
• Max. Digging Depth：6610mm
• Max. Digging Height：9615mm
• Transport Package：Container,RO-RO
• Specification：8090* 2580* 2900 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：8429521200
• Production Capacity：100,Month

ItemUnitZE210EKey    ParameterWorking masskg21300Rated powerkw/rpm112/1950Standard bucket capacity(SAE)m30.9System    flow
(Max. pressure/ Max. flow)-32.1/35    Mpa
   2×206 L/minEngine model-
   B5.9-C(150hp)Max. torqueN.m/rpm614/1500Traveling speed (low/high)km/h3.3/5.5Slewing speedrpm11.5Gradeability°°35°Max.  drawbar pullkN192Digging force of bucket (ISO)kN147Digging force of stick (ISO)kN103Basic    ParameterSlewing radius of tailmm2840Tail lengthmm2800Counterweight ground clearancemm1050Min. ground clearancemm440Ground contact lengthmm3380Track lengthmm4180Track gaugemm2200Track widthmm2800Track shoe widthmm600Height of grousermm26Slewing table widthmm2720Operating    RangeMax. excavating radiusmm9830Max. excavating distancemm9650Max. excavating heightmm9615Max. discharging heightmm6785Max. excavating depthmm6610Max. vertical excavating depthmm5760Min. slewing radius of frontmm3290
