• Model NO.：E6135F
• Size：Small-Scale
• Certification：ISO9001: 2000
• Condition：New
• Overall Operating Weight：12500kg
• Max. Digging Radius：7790mm
• Max. Digging Depth：5060mm
• Max. Digging Height：7900mm
• Engine Brand：Duetz
• Engine Type：Inter-Cooled, Four-Cylinder
• Engine Power：75kw
• Emission Standard：Tier III
• Min. Fuel-Consume Ratio：224G,Kw.H
• Hydraulic Control Type：Pilot Proportional Control Valve
• Hydraulic System Type：Constant Power Negtive Flow Control
• Transport Package：RO-RO, Container
• Specification：2450*2490*2830mm
• Trademark：SDLG
• Origin：Linyi, Shandong, China
• Production Capacity：50000unit,Year

Overall dimension Overall width of upper assembly2450mm Overall width2490mm Overall height2830mm Tail swing radius2200mm Overall height of engine hood2080mm Ground clearance of counterweight900mmWheelbase2700mm Crawler length3440mm Crawler gauge1990mm Crawler pad width 500mm Min. ground clearance430mm Overall length7340mm Overall height of boom2830mmOverall parameters Bucket capacity 0.48m³ Overall operating weight 12300kg Max. excavation force 85KN Slew speed 11r/min Traveling speed (low/high) 3.0/5.1km/h Average ground pressure 40.9kPa Max. digging radius 7790mm Max. digging depth 5060mmMax. digging height 7900mm Max. dumping height 5625mm Min. front slewing radius 2642mm Engine ModelBF4M2012Type Four-stroke,inter-cooled, superchargedRated Power@Revolution Speed 75kWDisplacement 4038mL Cylinder bore × stroke 101*126mm Emission standard GB20891-2014 China Phase III Rated fuel consumption 224g/kw.h Max. torque 425N.m Traveling/swing system Qty. of carrier rollers (single side) 1Qty. of track rollers (single side) 6Traveling brake type Wet disc brakeSwing mode Hydraulic drive internal tooth
single-row ball-bearing Swing brake type Wet disc brakeHydraulic system Hydraulic control type Pilot proportional control valveHydraulic system type Single pump load sensing systemMax. flow 220+20Operating pressure 330kgf/cm2Fill capacity Fuel 260L Engine oil 13L Hydraulic oil 205L Antifreeze 23L
