• Model NO.：JBS30-JZC350 concrete mixer with pump
• Productivity：50m²,h
• Feeding Height：1500mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：on Request
• Power：45kw
• Theoretic Output：30m3,H
• Engine：Diesel
• Theoretic Outlet Pressure：10MPa
• Theoretic Delivery Height：130m
• Max Pressure：10MPa
• Hopper Volume：350L
• Distribution Valve Type：S Pipe Valve
• Concrete Cylinder Spec.：160X1000
• Name：30m3,H Small Mobile Concrete Mixer with Pump Price
• Transport Package：20gp for Concrete Mixing Pump
• Specification：ISO certification
• Trademark：FOCUS
• Origin：Zhengzhou, China
• HS Code：84134000
• Production Capacity：60sets Per Month

Basic Info.

Model NO. JBS30-JZC350 concrete mixer with pump Productivity 50m²/h Feeding Height 1500mm Certification ISO9001: 2000, CE Condition New Color on Request Power 45kw Theoretic Output 30m3/H Engine Diesel Theoretic Outlet Pressure 10MPa Theoretic Delivery Height 130m Max Pressure 10MPa Hopper Volume 350L Distribution Valve Type S Pipe Valve Concrete Cylinder Spec. 160X1000 Name 30m3/H Small Mobile Concrete Mixer with Pump Price Transport Package 20gp for Concrete Mixing Pump Specification ISO certification Trademark FOCUS Origin Zhengzhou, China HS Code 84134000 Production Capacity 60sets Per Month

Product Description

30m3/h small mobile concrete mixer with pump price

 Why would our clients choose FOCUS trailer Concrete Mixer with Pump?
1.Double open hydraulic loops (pumping hydraulic circuit is independent of distributing hydraulic circuit) with two pumps, makes the whole hydraulic system much simpler. The reliability of the whole system is also much higher as well as the components' life is prolonged greatly. This is convenient for judgeing and removing trouble.
2.Large valve changing direction, makes the main pumping loop quick response, small leakage, good stability,high reliability and high resist contaminative capability.
3.Hydraulic system has safe relief protection,at the same time,when the system pressure is over, the main oil pump cutting device makes itself be protected reliably.
4.Distributing hydraulic circuit adopts constant pressure pump, which can provide strong distributing pressure and economic energy control.
5.Cone sealing of all pipes make the pipe joints seal reliably.
6.The  high-low pressure switch adopting cartridge valve of reduces the trouble of dismantling and installing the oil pipe.
7.Adopt emulsification technology of initiative and passivity recovery integration.
8.Compared with domestic product, the electric control system is simplest, the element quantity is fewest and its reliability is highest.
9.The wire remote equipment is convenient for operation far away.
10.Adopting proximity switch in hydraulic cylinder can realize changing direction with non-touch, which ensures that the direction can be changed reliably.
11.The design of hopper and S valve and so on adopt I-DEAS software to caculate, the hopper and S valve have good rigidity to avoid the phenomenon of hopper distortion and S valve breakage.
12.The agitator have unique form, which separates the hydraulic motor from agitator bearing pedestal.At the same time, adopting large displacement motor ensures that the agitator moment is big enough.
13.Make sure the pumping is good and decline the phenomenon of pipe jam, the spectacles wear plate and cutting ring should be useed in lower abrasion. FOCUS's spectacles wear plate and cutting ring use high wear material, making the components' life prolonged greatly.
14.The hydraulic circuit will take high oil into double distributor,and then the lubricating part can obtain hydraulic oil.It ensures the lubrication of the concrete cylinder's piston and other parts and prolongs the life of piston and other sealings.
15.The radiator equipment makes the working oil temperature of hydraulic system below 70ºC and makes the machine in normal status.


FOCUS Concrete Mixer with Pump main parameters:

Item	Unit	JB30R-JZC350
Rated Output	M3/h	30
Max. Pressure On Concrete	Mpa	10
Delivery Cylinder	Mm	140*1100
Main Oil Cylinder Bore/Rod Diameter X	Mm	80/55*1200
Oil Tank Capacity	L	250
Outlet Opening Diameter	Mm	100
Inner Dia. of Delivery Pipe	Mm	100
Diesel Model		WEIFANG4100
Diesel Power	KW	62
Max. Diameter Of Aggregates	Mm	30
Maximum Delivery Horizontal Distance	M	600
Maximum Delivery Vertical Distance	M	120
Mixer Type		JZC350
Capacity of Charge	L	560
Capacity of Discharge	L	350
Water Pump Motor Control		Electromagnetic
Diameter of Drum	Mm	1440
Mixing Time	S	45-60
Length×Width×Height	Mm	5500*2300*2700
Weight	Kg	5000

Concrete Mixer with Pump:
1.great mobility, very low price;
2.ISO and CE certified with 12 months warranty;
Our trailer Concrete Mixer with Pump have been purchased, installed and operated all over the world:

Thanks for visiting, our trailer Diesel Concrete Mixer with Pump have been delivered /distributed to the world, it'll be such a great honor if you can join us:
