• Model NO.：XN10
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Engine Brand：Changchai
• Power：7500
• Hydraulic Pump Brand：Kdk
• Core Components：Engine, Motor, Pump
• Loading：12 Units in 40FT
• Machinery Test Report：Provided
• Hydraulic Valve Brand：Taigfeng
• Maximum Digging Height：1400mm
• Hydraulic Cylinder Brand：Yelong
• Video Outgoing-Inspection：Provided
• Engine Type：Single Cylinder Diesel Oil Engine
• Main Pump：Cbk-F6.8
• Maximum Digging Depth：1500mm
• Rated Speed：1.5km,H
• Operating Weight：800
• Transport Package：Wooden Box
• Trademark：RHINOCEROS
• Origin：Shandong, China
• Production Capacity：100000PCS Per Year

Type

XN10

Total weight

800KG

Bucket capacity

0.025 M3

Overall height

1330mm

Overall length

2550mm

Maximum dig radius

2650mm

Dig radius at ground line

2400mm

Maximum dig depth

1400mm

Dump height

1750mm

Vertical straight wall dig depth

1320mm

Lift above Dozer

325mm

depth of dozer blade

175mm

Counter weight turning radius

733mm

Arm digging force

4.8kn

Bucket digging force

9.2kn

Engine model

Koop / changchai

Cooling

air-cooling

System relief pressure-Standard

16MPa

Main Features

1.Changchai/Koop/Yanmar,7.5 /7.6 /10 kw,single cylinder,air-cooled,national II emission standard.

2.0.8 ton ,0.025cbm bucket 1.5km/h,1877x896x1990 mm.
3.Max. Digging height:2365mm, Max. Digging depth:1500mm.
4.It also can be with,auger gripper,ripper,rake ,500mm Leveling bucket and 200mm Narrow bucket if you'd like.

Packaging& Shipping

If you need 1-3 units would be Wooden box, More than 4 units will loading by container

After 5-7 days we will shipping your goods when we received the advance payment
