• Model NO.：CLG4215
• Walking Mode：Wheeled
• Type：Medium-sized Grader
• Rated Power/Speed：160kw
• Total Weight：16500kg
• Maximum Speed：40.3km,H
• Blade Width：4572mm
• Maximum Overall Height：3500mm
• Specification：9385*2600*3580mm
• HS Code：8501109190
• Production Capacity：200

Engine 6A8.3Rated Power(kW)160 (215 hp) @ 2,200 rpmMaximum Speedkm/h (mph)42 (26)Operating Weightkg(Lb)15500(34172)ENGINETier IIMake 6BTAA5.9-C190Net PowerkW(Hp)@rpm144 (193 hp) @ 2,200 rpmPeak Torque 800N.m/1500rpmTorque Rise % 41%Number of Cylinders 6Aspiration turbo air-to-air aftercooledTRANSMISSIONTransmission Type power shiftTransmission Configuration 6f/3rTorque Converter three-member single turbineMaximum Travel Speed, fwd(km/h)42Maximum Travel Speed, rev(km/h)26.1Number of Speeds, fwd 6Number of Speeds, rev 3AXLESFront Axle Make LiuGong Weld axleRear Axle Make MeritorDifferential Type NO-SPIN limited slip standardFinal Drive Type chain driveAxle Oscillation ±15°Front Axle Type all welded steel frameFront Axle, Wheel Lean Angle ±17°STEERINGSteering Configuration load sensor steering gearSteering Relief Pressure(Mpa)17Minimum Turning Radius(inches)7800(307)Steering Angle ±45°Frame Articulation Angle ±20°
