Summary

Rated Load:6000

Type:Front Loader

Place of Origin:China

Model Number:LW600KN

Brand Name:XCMG

Certification:CE/ISO9001

Dimension(Long*Breadth*High):8505×3220×3515mm

Details

Product Name:LW600KN

Display online time:2018-11-21

weight:20000.000kg

After-sales Service Provided:Engineers available to service machinery overseas

Warranty:12 Months

Condition:NEW

Moving Type:wheel

Rated operating load:6000kg

Bucket capacity:3.0~4.5m3

Machine weight:20000kg

Dump clearance at maximum lift:3170~3750mm

Reach at maximum lift:1200~1360mm

Wheel base:3350mm

Tread:2265mm

Max.breakout force:205kN

Engine Model:SC11CB240.1G2B

Rated Power:178kW

Tyre specification:23.5-25

Advantage

1,The high-efficiency electronic control counter shaft transmission matches perfectly with the engine.

2,The three-stage air filter is designed especially for severe working environment of construction machinery industry.

3,The material and heat treatment for pump shaft connecting spline are improved and the forced lubrication is applied to prolong the life by 20%.

4,With optimized materials and processes, the main reducer and wheel reducer passed the industry's leading reliability life test of >900,000 cycles.

5,The double-pump confluence/distribution technology is applied so that the steering pump preferentially supplies oil to the steering system.
