Description | Unit | Parameter value |
Outline dimension | mm | 12510×2500×3990 |
Overall weight | kg | 33000 |
Chassis | Model | | ZZ5347V484MC1 |
Max. speed | km/h | 90 |
Max. grade-ability | % | 40 |
Wheelbase | mm | 4800+1400 |
Tire | | 315/80R22.5 |
Engine | Model | | MC11.40-30 |
Max. power | kW | 297 |
Max. torque | N·m/(r/min) | 1900/1000~1400 |
Displacement | L | 10.518 |
Emission standard | | Eruo III |
Pumping system | Theoretical output | m3/h | 170 |
Concrete pumping pressure | MPa | 8 |
Theoretical pumping times | Time/min | 23~26 |
Delivery cylinder diameter ×stroke | mm | φ260×2000 |
Max. diameter of pumping concrete | mm | ≤40 |
Filling height | mm | 1580 |
Concrete slump range | cm | 8~23 |
Placing boom | Reach height | m | 47.5 |
Reach depth | m | 34 |
Slewingradius | m | 43.5 |
Slewing angle | ° | ±270 |
Unfolding angle of the 1st section | ° | 90 |
Unfolding angle of the 2nd section | ° | 180 |
Unfolding angle of the 3rd section | ° | 180 |
Unfolding angle of the 4th section | ° | 240 |
Unfolding angle of the 5th section | ° | 210 |
Unfolding angle of the 6th section | ° | 120 |
Stabilizer span | Longitudinal span of stabilizer | mm | 8955 |
Transverse span of front stabilizer | mm | 7884 |
Transverse span of rear stabilizer | mm | 9940 |
Others | Lubrication method | | Automatic lubrication |
Control method | | Manual/remote control |
Volume of water box | L | 1300 |
