15 Ton Three Wheel Static Road Roller 3y152j
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Road Roller
- Working Method：Steel Wheel
- Axle：Triaxial Three-Wheel
- Grinding Wheel Type：Tire Grind
- Compaction Depth：25cm
- Engine Type：Diesel Engine
Base Info
- Model NO.：3Y152J
- Travel Speed：30cm,s
- Centrifugal Force：14KN
- Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
- Condition：New
- Brand Name：Oriemac
- Engine：Cummins
- Transport Package：Nude Packing
- Specification：Middle size
- Trademark：Oriemac
- Origin：Jiangsu, China
- Production Capacity：500,Month
Description
Basic Info.
Model NO. 3Y152J Travel Speed 30cm/s Centrifugal Force 14KN Certification EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008 Condition New Brand Name Oriemac Engine Cummins Transport Package Nude Packing Specification Middle size Trademark Oriemac Origin Jiangsu, China Production Capacity 500/MonthProduct Description
15 ton three wheel static road roller 3Y152JOperating weight: 12000 kg
Max. Operating weight: 15000kg
Yuchai YC4D85Z-T20 engine, 60kw
| Model | Unit | 3Y152J |
| Operation weight | kg | 12000 |
| Max. operation weight | kg | 15000 |
| Rear wheel max. static load | N/cm | 1029 |
| Travel speed | km/h | |
| Speed I | 3.08 | |
| Speed II | 5.36 | |
| Speed III | 12.01 | |
| Reverse speed I | 3.12 | |
| Reverse speed II | 5.43 | |
| Theoretical gradeability | % | 20 |
| Min. external turning radius | mm | 6000 |
| Min. ground clearance | mm | 488 |
| Compaction width | mm | 2120 |
| Roller overlap amount | mm | 100 |
| Engine model | YC4D85Z-T20 | |
| Type | Water cooling | |
| Max. power @2200 r/min | kw | 60 |
| Overall length | mm | 6224 |
| Overall width | mm | 2120 |
| Overall height | mm | 3297 |
| Hydraulic oil tank capacity | L | 70 |
| Diesel oil tank capacity | L | 130 |
| Engine oil consumption | g.kW/h | 22 |
