• Model NO.：SD13
• Condition：New
• Color：Green
• Transport Package：Nude
• Trademark：SHANTUI
• Origin：Xuzhou, China

Basic Info.

Model NO. SD13 Condition New Color Green Transport Package Nude Trademark SHANTUI Origin Xuzhou, China

Product Description

1 The extended track ensures low ground pressure, high reliability and strong traction, contributing to precise operation;

2 The power shift transmission not only ensures smooth power shift, but also reaches target speeds and carries out directional transfers with a single control lever;

3 The wet steering clutch and brake can extend service life. They work interactively, ensuring quick and flexible steering operations;

4 The single control lever can control all blade actions

5 The drift sealing in the drive wheel, track roller and carrier roller can prevent dust from entering the track system, as well as lubricant leakage, thereby ensuring a long service life;

6 The hexahedron cab features wide visibility, and the insulation materials in the cab can reduce noise and vibrations;

7 The spin type fuel filter and dust separator, the air filters and the other filtration devices can prolong work time and reduce service time;

8 The comfortable cab seat can adjust upward and downward, forward and backward, meeting any positional needs the operator may have;

9 Side engine operation and the combination of a drive/brake operation system and foot brake makes overall operation of the bulldozer more rapid and convenient.

Main Specification	Unit	SD13
Overall Dimension L*W*H	mm	4492*3185*2950
Operating Weight	t	13.7
Rated Power/Speed	kw/rpm	100/1900
Track Center Distance	mm	1880
Ground Contact Land	mm	2365
Land Pressure	Mpa	0.063
Forward Travelling Speed	km/h	3.2/5.9/9.8
Reverse Travelling Speed	km/h	3.9/7.1/11.9
Blade Digging Depth	mm	590
Ripper Breaking Depth	mm	467
Blade Lifting Height	mm	930
Ripper Lifting Time	mm	559
Grade Ability		30°
Blade Capacity	m3	Straight 3.7,Angle 3.4
Engine Model		SC8D143G2B1
No. of Carry Rollers (Each Side)		2
No. of Track Rollers (Each Side)		6
No. of Track Link	mm	38
Track Width	mm	460
Pitch	mm	190
Blade Type		Stragiht ,Angle ,U
Blade Length*Width	mm	Straight3185*1090, Angle 3745*915
Ripper Type (tooth)		Three
