3ton Rated Load Wheel Loader for Sale (W136)

Shanghai YingXin World Machinery Co., Ltd.
  • Certification：CE, ISO9001: 2000
  • Condition：New
  • Transmission：Hydraulic - Mechanical Transmission
  • Walking Mode：Wheeled
  • Type：Medium-sized Loader
  • Wheel Loader for Sale：Wheel Loader 3 Ton

Base Info

  • Model NO.：W136
  • Bucket Capacity：1.8cbm
  • Operation Weight：10ton
  • Engine Brand：Cummins or Deutz
  • Gearbox：Zl30 Planet Type
  • Service Brake：Air Active Oil, Brake Shoe with Disc
  • Tyre Size：17.5-25
  • Cabin：Air Conditioned
  • Options：Grapple, Fork
  • Delivery Time：30 Days
  • Usage：Universal Type
  • Scraper Type：Pull Scraper
  • Load and Unload Method：Front Discharge
  • Engine Power：74~147kw
  • Color：Yellow
  • Transport Package：in Container
  • Specification：Iso Ce
  • Trademark：WORLD
  • Origin：China
  • HS Code：84295100
  • Production Capacity：5000 PCS,Year

Description

Basic DataBucket Capacity1.8m³Rated Load3200kgTravelling SpeedForward 1st0-10.8km/hForward 2nd0-32.5km/hReverse 1st:0-14.5km/hMax.Traction97kNMax.Break Out Force100kNMin.Turn Radius (outside tyre)5376mmMax. Dumping Height3060mmMax. Reach1008mmTotal Hydraulic Cycle Time≤10.3sFull Bucket Lifting Time≤5.6sWheel Base 2750mmDimensions (LxWxH)6970x2450x3286mmMin. Clearance Over Ground360mmOperating Weight10000kg
 Diesel EngineModelCummins 6BT5.9 or Duetz TD226B or Yuchai YC6B125TypeDirect injection, water cooling, 4 strokes Rated Output97/92/92kWRated Speed2200rpmMax. Torque560N.m/500N.m/460N.m
 Transmission  Hydraulic Torque Converter ModelSingle stage, two phase, four componentsTransmission Type2 forward and 1 reverse gears/hydraulic power shift, planet typeMax.Permissible Temp.120
 Transaxle & Tyre Drive System4 wheel drive Type of main ReducerSpiral bevel gear, single stageType of hub ReducerPlanet gearTyre  Size17.5-25Pressure Of Tyre0.28-0.32MPa
 Working Hydraulic SystemWorking Pump TypeGear PumpSystem Working Pressure16MPaLifting Cylinder Bore x Stroke125x816mmTilting Cylinder Bore x Stroke140x553 mm
 Steering System Typefull hydraulic power steering system Steering Pump TypeCBY2050  (reverse)Max. Working Pressure10MPaSteering Cylinder Bore x Stroke80x340mmMax. Steering Angle±36 º
 Brake System TypeCaliper disc brake, air over oil activate, 4 wheel brakeDrive Brake System Pressure0.71-0.784MPaParking BrakeHand brake, drum type
 Oil Injection CapacityFuel Tank150LEngine Oil15LTransmission27LHydraulic Oil Tank140LTransaxle30L
