• Model NO.：XE85C
• Size：Large-Scale
• Certification：CE
• Condition：New
• Operating Weight：8.1kg
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• HS Code：87059091
• Production Capacity：10000,Year

  UnitParametersModelOperating weightKg8500Bucket capacityM³0.14


EngineEngine model/4TNV88Direct injection/√4x strokes/√Water cooling/√Cylinders/4Output power of engineKW/rpm27.6/2200Max torque/speedN.m/rpm142/1320DisplacementL2.19

Main
performanceTravel speedKm/h4.2/2.6Slewing speedr/min13.5Gradient capability°30°Ground pressurekPa36.3Digging capacity of bucketKN23.2Digging capacity of bucket rodKN19.3Max traction forceKN33.9
Hydraulic
systemRated flow of main pumpL/min1x110+11Pressure of main sadety valveMPa21Pressure of traveling systemMPa21Pressure of swing systemMPa21Pressure of pilot systemMPa3.9
Oil volumeFuel tank capacityL65Hydraulic tank capacityL70   UnitParametersApperance
SizeTotal lengthmm5455 Total widthmm1650Total heightmm2440Width of rotary tablemm1500Total width of chassismm1635Track widthmm300Treadmm1721Track gaugemm1335Ground clwaranance of counterweightmm578Min.ground clearancemm350
Company profile
XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2015, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.

At present, the power of my company's straight-arm crane is entirely from the hydraulic oil pressure, that is, through the high-pressure hydraulic oil to promote the cylinder piston reciprocating motion, or drive the hydraulic motor rotation makes the hydraulic winch and rotary mechanism rotation.

So, how do high-pressure hydraulic oil get? Each truck crane is equipped with a hydraulic pump when the vehicle chassis is matched, and the engine provides power for it. The chemical energy of the fuel can be converted into the crankshaft of the engine to rotate the mechanical energy, and then the gearbox gear is rotated, and then the power is transmitted to the hydraulic pump through the power transmission of the gearbox. Therefore, the hydraulic pump can continuously pressurize the hydraulic oil For the high-pressure hydraulic oil, so as to provide power for the crane to achieve the lifting of the goods.
