• Model NO.：GR500
• Origin：Jiangsu Xuzhou
• Production Capacity：1000sets,Month

GR500Basic specificationEngine modelQSX15Rated power/speed399kW/2100rpmDimension(LxWxH)14321×4165×4624mmOperating weight(Standard)56000kgPerformance specificationTravelling speed ,forward0~38 km/hTravelling speed ,reverse0~38 km/hTractive force(f=0.8)370KNMax. gradeability30%Tire inflation pressure400 MPaWorking hydraulic pressure22 MPaTransmission pressureOperating specificationMax. steering angle of front wheels49°Max. lean angle of front wheels17°Max. oscillation angle of front axle15°Max. oscillation angle of balance box15Frame articulation angle27°Min. turning radius using articulation12.4mBiadeMaximum lift above ground650mmMaximum depth of cutting680mmMaximum blade position angle40°Blade cutting angle40°_80°Circle reversing rotation120°Moldboard width X height7300×1067mm
