Earthmoving Machinery Chenggong 5 Ton Mini Wheel Loader Cg956c
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE
- Condition：New
- Rated Load：5 T
- Transmission：Hydraulic
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：Cg956c
- Type：Large Loader
- Brand：Chenggong
- Transport Package：Nude, 40hq
- Specification：16600 kg
- Trademark：CHENGGONG
- Origin：Sichuan, China
- HS Code：8429510000
- Production Capacity：1000pieces,Year
Description
Basic Info.
Model NO. Cg956c Type Large Loader Brand Chenggong Transport Package Nude, 40hq Specification 16600 kg Trademark CHENGGONG Origin Sichuan, China HS Code 8429510000 Production Capacity 1000pieces/YearProduct Description
Earthmoving Machinery Chenggong 5 Ton Wheel Loader Cg956c| Engine model | Weichai WD10G220E23 |
| Rated power | 162kw @ 2000 rpm |
| Rated load | 5 tons |
| Dump height (45 ° ) | 3182mm |
| Dump reach (max. dump clearance) | 1075mm |
| Max. forward speed | 36km/h |
| Min. turn radius | 6570mm |
| Standard bucket capacity | 3.0 m 3 |
| Max. breakout force | 180KN |
| Action time of working device | 10.7s |
| Lifting time of working device | 6.0s |
| Wheel base | 3280mm |
| L×W×H | 8100×3000×3470mm |
| Operating mass | 16600kg |
