• Model NO.：T165-3
• Transport Package：Nude Package
• Trademark：HBXG

Basic Info.

Model NO. T165-3 Transport Package Nude Package Trademark HBXG

Product Description

High Quality China HBXG bulldozer Track Pad Bulldozer T165-3

FEATURES



• T165-3/TS165-3 bulldozer is semi-rigid suspended, direct drive transimission, track-type undercarriage, pilot implement control.
• T165-3 serial bulldozers are an upgrade product on the basis of T165-2 serial bulldozer. Comparing with the T165-2 serial bulldozer, T165-3 serial bulldozer are improved with respect to the performance, appearance, inner-decoration of the CAB with the application of the Sand-filtering air- filter system, Pre-heating device of fuel, Electronic-control fuel-feeding device, as well as the improvement of the structure of radiator support and blade of implement.



Specification for TY165-3



T165-3 Bulldozer	Unit	165HP
Model		T165-3
L*W*H(Ripper not included)	mm	5447*3297*3160
Operating weight(Ripper not included)	kgs	17120
Engine Model		WD10G178E25
Rated Power	kw/rpm	131/1850
Gradeability(Longitudinal/Transverse)	°	30/25
Blade type		Straight tilt blade
Blade width Dozing capacity Max. drop below ground of blade	mm m3 mm	3297 4.6 420
Max. lift height of blade	mm	900
Ripper type		Three shanks ripper
Max. digging depth of Ripper	mm	550
Max. lifting height of ripper	mm	510
Min. ground clearance	mm	352.5
Number of carrying roller(each side)		2
Number of track roller(each side)		6
Forward speed	km/h	1st 0~2.52 2nd 0~3.32 3rd 0~5.68 4th 0~7.53 5th 0~10.64
Reverse speed	km/h	1st 0~3.53 2nd 0~4.6 3rd 0~7.94 4th 0~10.53
