• Model NO.：3m
• Motor Power：85
• Noise：Without Noise
• Certification：CE, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Product Number：Hwl300r
• Hydraulic Hammer Model (mm)：75,85,100 Optional
• Hydraulic Hammer Flow (L/Min)：50-110
• Impact Frequency (BMP)：350-800
• Drill Rod Diameter (mm)：75,85,100
• Walking Motor Torque (N.M)：<11500
• Pile Height (mm)：According to The Slide
• Sliding Guide Frame Inclination Angle：(Left) 5(Right) 5
• Frame Rotation Angle (°)：360
• Hydraulic System Pressure (MPa)：22
• Gear Pump Displacement (Ml/R)：40+40+25
• Traveling Speed (Km/H)：3
• Vehicle Weight (Kg)：6200
• Engine Power (Kw)：85
• Engine Rated Speed (R/Min)：2600
• Transport Package：Standard Package
• Specification：300
• Trademark：HW
• Origin：China
• Production Capacity：5000

Product Parameters

Product number

HWL300R

Hydraulic hammer model (mm)

75/85/100 optional

Hydraulic hammer flow (L/min)

50-110

Impact frequency (bmp)

350-800

Drill rod diameter (mm)

75/85/100

Walking motor torque (N.m)

<11500

Pile height (mm)

According to the slide

Sliding guide frame inclination angle (°)

(Left) 5(Right) 5

Frame rotation angle (°)

360

Hydraulic system pressure (mpa)

22

Gear pump displacement (ml/r)

40+40+25

Traveling speed (km/h)

3

Vehicle weight (kg)

6200

Engine power (kw)

85

Engine rated speed (r/min)

2600

Track shoe width (mm)

350

Track single (section)

42

Total displacement of walking motor (ml/r)

53

Rated pressure of walking motor (mpa)

30

Travel motor reduction ratio

1:54.4

Dimensions (mm)

FAQ
1) ,What is your terms of payment?
TIT 30% as deposit, and 70% before delivery. We'll show you the photos of the products and
packages before you pay the balance.

2), What is your terms of delivery?
EXW, FOB, CFR, CIF.

3),How about your delivery time?
Generally, it will take 7-10 working days after receiving you advance payment The specific
delivery time depends on the items and the quantity of your order

4),What is the warranty of our machine?
Our main machine enjoys a?1 year warranty(except for the hammer). during this time all
accessories broken can be changed for a?new one And we provide videos for machine install and
operation.

5), What is your terms of packing?
Generally, we use standard exported wooden case for LCL goods, and fixed well for FCL goods.

6),Do you test all your goods before delivery?
Yes, we have 100% test before delivery.And we will attach our inspect report for every machine.

7),Do you Preferred provide wear parts for transacted clients?
Yes, we have records for your clients, and will prefer providing accessories to clients.

8)How do you make our business long-term and good relationship?
1 We keep good quality and competitive price to ensure our customers benefits;
2 We respect every customer as our friend and we sincerely do business and make friends with
them, no matter where they come from.


9), Do you have any certificates for your machine??
All of our products coming with the
certificates of CE, S09001.
