8 10 12 16 Ton Truck Mounted Crane with High Lifting Height
Hubei Suny Automobile and Machinery Co., Ltd.- Driving Type：6X4
- Chassis Brand：Dongfeng, Option JAC, Isuzu
- Tires & Quantity：10.00r20 & 10+1
- Wheelbase：4350+1300 mm
- Chassis Model：EQ5201gfj6
- Gear Box：8 Forwards &1 Reverse
Base Info
- Engine Model：B210 33 (Euro III Emissions Standard)
- Maximum Power：155 Kw , 210 HP
- Max Lifting Capacity (Kg)：10000
- Max Lifting Moment (T.M)：20
- Crane Weight(Kg)：3477
- Installation Space(mm)：1150
- Max. Operating Diameter (M)：12
- Max. Lifting Height (M)：14
- Max Pressure of Hydraulic System(MPa)：28
- Transport Package：Bulk and Wax Covered
- Specification：CE
- Trademark：Dongfeng
- Origin：China
- HS Code：8705909090
- Production Capacity：2000units Per Year
Description
12 month from date of supply
Technical parameters of crane:
1.The truck mounted crane is also named truck with loading crane. It consists of chassis, packing case (cargo box), power take-off, and crane.
2.It is widely used in city construction, coal mining engineering, gardens Greening for lifting and transporting the basic construction materials and so on.
3.Our truck mounted crane has compact fixing space, light dead weight, and big loading weight. The design is safe and reliable, nice appearance. Support oil cylinder can be overturned manually, thus improve the Cross-country performance of the whole machine. Planetary lift hoist efficiently decrease the system temperature, fast and smart working speed, very durable truck.
4.The mounted crane can select to equip with DONGFENG, FAW, FOTON, CINOTRUCK, JAC, CAMC,IVECO and other chassis. 1t,2t,3.2t,4t,5t,6.3t,8t,10t,12t,14t,16t crane can be equipped according to different machine model. The telescopic straight boom crane and folding type crane are also for your options.
5.Outrigger style: adopting horizontal telescopic H shape Outrigger, all outriggers can be independently adjusted to regulate the whole frame balance, it has large outrigger span, the whole machine has very good stability.
6.The operation mode: left and side double side operation, the slewing angle is: ±360°, continuous slewing, and hand throttle can adjust the slewing speed and lifting speed. rotation speed hand throttle adjustable and lifting speed.
