• Model NO.：FR260D FR330D
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Transport Package：Nude, Suitable for Shiping
• Specification：ISO
• Trademark：LOVOL
• Origin：Jiangsu, China
• HS Code：1
• Production Capacity：100 Sets,Month

Main ParametersOperation Weight (Standard Configuration) (KN)25050Standard Bucket Capacity1.2Transport Dimensionsmm9945*3180*3255Bucket Digging Force (KN)172Bucket Rob Digging Force (KN)129Maximum Traction (KN)247DeviceHigh-low Speed (Km/h)4.8/3.4Climbing Performance(°)30Total Length of the Crawler4660Tail Turning Radius (mm)2945Width of the Crawler600Ground Pressure (Kpa)51Turning MechanismTurning Speed (rpm)12.2EngineModel6BG1TRP Isuzu 6BG1TRPFormSix Cylinders, Straight, Four Strokes, Direct Injection, Turbocharger, Air Inter CoolingRated Power/Rotate Speed (KW/rpm)125/2100Rated Torque/Rotate Speed (N.m/rpm)637.9/1800Cylinder Diameter*Stroke (mm)105*125Output Value (L)6.494Fuel Consumption (g/KW.h)237Hydraulic SystemFuel Tank Capacity (L)385Main Pump Pressure (Mpa)32/35Main Pump Flow240*2Operating ScopeMaximum Digging Height (mm)10220Maximum Dumping Height (mm)7210Maximum Digging Depth (mm)6920Maximum Digging Radius (mm)10210
