• Model NO.：DH17-B2
• Engine Power：140kw
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Yellow
• Operating Weight (Kg)：17500(Ripper Not Included)
• Ground Pressure (Kpa)：64
• Engine Model：Weichai Wd10g190e214
• Rated Power/Rated Speed (Kw/Rpm)：140,1900
• Forward Speed (Km/H)：0-10
• Reversing Speed (Km/H)：0-10
• Center Distance of Track (mm)：1880
• Width of Track Shoes (mm)：510,560,610
• Ground Length：2675mm
• Fuel Tank (L)：305
• Blade Type：Semi-U,Straight-Tilt
• Digging Depth (mm)：520
• Ripping Depth (mm)：475
• Ripper Type：3 Shank
• Transport Package：Nude Package,RO-RO,Bulk Shipment,Suitable Contain
• Specification：5250*3420*3080
• Trademark：shantui
• Origin：China
• Production Capacity：300piece,Month

Basic Info.

Model NO. DH17-B2 Engine Power 140kw Certification CE, ISO9001: 2000 Condition New Color Yellow Operating Weight (Kg) 17500(Ripper Not Included) Ground Pressure (Kpa) 64 Engine Model Weichai Wd10g190e214 Rated Power/Rated Speed (Kw/Rpm) 140/1900 Forward Speed (Km/H) 0-10 Reversing Speed (Km/H) 0-10 Center Distance of Track (mm) 1880 Width of Track Shoes (mm) 510/560/610 Ground Length 2675mm Fuel Tank (L) 305 Blade Type Semi-U/Straight-Tilt Digging Depth (mm) 520 Ripping Depth (mm) 475 Ripper Type 3 Shank Transport Package Nude Package/RO-RO/Bulk Shipment/Suitable Contain Specification 5250*3420*3080 Trademark shantui Origin China Production Capacity 300piece/Month

Product Description

China Shantui 17500 kg/19360 kg Bulldozer DH17-B2 With Free Spare Parts


CHARACTERISTICPower System

Weichai mechanical engine conforms to the China-II non-road machinery emission regulation, featuring high intelligence and efficiency, simple structure, high parts interchangeability, and low maintenance cost.

The intelligent match technology can achieve best working efficiency and most reasonable fuel economy, with the composite fuel consumption reduced by 10~15%.

Control system

The double-module (Function and safety) controller architecture verifies with each other to achieve higher safety and reliability.

The malfunction self-diagnosis function is provided to accurately indicate the malfunction cause and orientation and shorten the downtime.

The service software with distinct access hierarchy features high simpleness and practicability and easy learning and understanding.

Driving/Riding Environment

The integral ergonomic hexahedral cab features large space, excellent vision, and good airtightness.

The suspended single accelerator pedal features small volume, large foot space, and high operation comfort.

The extensively adjustable seat and armrests provide the driver with the most comfortable operation posture.

The standard canopy and the optional standard cab + heating and A/C system are provided. The cab adopts integrally sealed shock-absorbing system and sound-absorbing sponge to lower the driver's parotic noise to 85dB and realize low vibration and noise.

The intelligent display and control terminal with integrated instruments, cigarette lighter, USB charging port, radio, toolbox, sun shade, and fire extinguisher to provide more abundant personalized driving/riding experience and guarantee the comfortable and safe driving/riding environment.

The safety passage system of the machine guarantees the driver's safety.

Working adaptability

The machine adopts double-circuit electronically controlled hydrostatic drive system to ensure good load self-adaptability, loaded and in-situ steering capability, stepless speed regulation, and high flexibility and efficiency and realize outstanding construction performance in narrow sites.

The undercarriage system features long ground length, high ground clearance, stable driving, and excellent trafficability. The standard traction frame and the optional three-shank ripper are provided.

The standard LED working lamps of higher illumination intensity improve the illumination capability during nighttime operations to achieve higher safety and reliability.

Easy maintenances

The structural parts inherit the excellent quality of Shantui mature products.

The electric harnesses adopt seamless corrugated pipes and deconcentrators for branching, featuring high protection grade.

The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.

The modular structure design of the machine features easy disassembling and assembling, simple repairs, low failure rate, and easy maintenances.

PARAMETER

Parameter name	DH17 B2 XL	DH17 B2 LGP
Performance parameters
Operating weight (Kg)	17500(Ripper not included)	19360
Ground pressure (kPa)	64	30
Engine
Engine model	Weichai WD10G190E214	Weichai WD10G190E214
Rated power/rated speed (kW/rpm)	140/1900	140/1900
Overall dimensions
Overall dimensions of machine (mm)	5250*3420*3080	5340*4150*3091
Driving performance
Forward speed (km/h)	0~10	0~10
Reversing speed (km/h)	0~10	0~10
Chassis System
Center distance of track (mm)	1880	2350
Width of track shoes (mm)	510/560/610	1100/950
Ground length(mm)	2675	2935
Tank capacity
Fuel tank (L)	305	305
Working device
Blade type	Semi-U/Straight-tilt	Straight-tilt
Digging depth (mm)	520	485
Ripper type	3 shank	-
Ripping depth (mm)	475	-
