• Model NO.：SD26
• Condition：New
• Color：Yellow
• Engine：206,1800 Kw,Rpm
• Ground Pressure：77kpa
• Center Distance of Track：2000mm
• Ground Length：2730mm
• Fuel Tank：450L
• Width of Track Shoes：560mm
• Transport Package：Container
• Specification：5495*3725*3402mm
• Trademark：SHANTUI
• Origin：China
• Production Capacity：50000pieces,Year

Basic Info.

Model NO. SD26 Condition New Color Yellow Engine 206/1800 Kw/Rpm Ground Pressure 77kpa Center Distance of Track 2000mm Ground Length 2730mm Fuel Tank 450L Width of Track Shoes 560mm Transport Package Container Specification 5495*3725*3402mm Trademark SHANTUI Origin China Production Capacity 50000pieces/Year

Product Description

SHANTUI Brand New SD26 260HP BulldozerEasy maintenances

The structural parts inherit the excellent quality of Shantui mature products.

The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.

The openable large-space side hoods make the repairs and maintenance easier.

All lubricating and maintenance points of machine are directed to the outer side of machine body to achieve convenient and rapid maintenances.

Working adaptability

Shantui's mature product chassis system is applicable to diversified severe working conditions, featuring high stability and reliability.

Long ground length, high ground clearance, stable driving, and good trafficability.

The straight tilting blade, semi-U blade, U-blade, angle blade, coal blade, rock blade, environmental sanitation blade, ripper, and traction frame can be installed depending on specific working condition to achieve higher working adaptability. The optional LED working lamps improve the illumination capability during nighttime operations to achieve higher safety and reliability.



Parameter name	SD26	SD26E(LONG TRACK)	SD26F(FOREST LOGGING)	SD26S(LGP)
Performance parameters
Operating weight (Kg)	23400	24600	24700	25700
Ground pressure (kPa)	77	72	66	41
Engine
Engine model	WEICHAI WP12	WEICHAI WP12	WEICHAI WP12	WEICHAI WP12
Rated power/rated speed (kW/rpm)	206/1800	206/1800	206/1800	206/1800
Overall dimensions
Overall dimensions of machine (mm)	5495*3725*3402	5495*3725*3402	5495*3725*3402	6225*4365*3402
Driving performance
Forward speed (km/h)	F1: 0-3.8 F2:0-6.8 F3:0-11.7	F1: 0-3.8 F2:0-6.8 F3:0-11.7	F1: 0-3.8 F2:0-6.8 F3:0-11.7	F1: 0-3.8 F2:0-6.8 F3:0-11.7
Reversing speed (km/h)	R1:0-4.5 R2:0-8.1 R3:0-13.9	R1:0-4.5 R2:0-8.1 R3:0-13.9	R1:0-4.5 R2:0-8.1 R3:0-13.9	R1:0-4.5 R2:0-8.1 R3:0-13.9
Chassis System
Center distance of track (mm)	2000	2000	2000	2250
Width of track shoes (mm)	560	560	560	910
Ground length(mm)	2730	3050	2730	3480
Tank capacity
Fuel tank (L)	450	450	450	450
Working device
Blade type	Straight-tilt	Straight-tilt	Straight-tilt	Straight-tilt
Ripper type	Single shank/3 shanks	Single shank/3 shanks	Single shank/3 shanks	--
Ripping depth (mm)	695/666	695/666	695/666	--
