• Model NO.：LW600-LNG
• Walking Mode：Wheeled
• Type：LNG
• Model Number：Lw600K-LNG
• Dimension：8695*3750*3020
• Rated Bucket Capacity：3.5m3
• Usage：Special Type
• Scraper Type：Tractor-Scraper
• Load and Unload Method：Front Discharge
• Engine Power：147~515kw
• Color：Yellow
• Time for The Entire Operating Flow：10.9s
• Rated Rotation Speed：2200r,Min
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• HS Code：87059091
• Production Capacity：1000,Year

Overview
Ordinary diesel loader's oil consumption cost per hour:17.5L*7.6Yuan/L=133Yuan Oil consumption is based on 17.5L/H
Whereas XCNG LW500K-LNG loader's gas consumption cost per hour is:21m³*4.3Yuan/m³=90.3Yuan Gas consumption is based on 21m³/H(15kg/H)
Cost saved per hour:133Yuan-90.3Yuan>42Yuan
Cost saved per day (based on 12working hours):42Yuan/H*12H>500Yuan
Cost saved per year (based on 300working days):500Yuan/Day*300days>150000Yuan
Fuel cost is saved bu more than 30%,showing a remarkable economuc efficiency
Main parameters
item
LW500K-LNG
LW600K-LNG
Unit
Rated bucket capacity
3
3.5
m³
Rated loading capacity
5000
6000
kg
Overall operating weight
17600
21000
kg
Discharge height
3090
3200
mm
Discharge distance
1130
1268
mm
Wheelbase
3300
3400
mm
Wheel track
2250
2265
mm
Min. ground clearance
440
467
mm
Body rotating angle
38
38
°
Overall length
8225
8695
mm
Overall height
3700
3750
mm
Bucket width
3016
3020
mm
Max. traction force
175
180
kN
Time for the entire operating flow
11
10.9
s
Engine
Model
SDEC SC9DT280G2
Weichai WP10NG260E30
Type
In-line,four-stroke,water-cooled,lean-burn,premixing,and supercharged inter-cooling
Rated power
170
191
kW
Rated rotation speed
2000
2200
r/min
Max. breakout force
170
201
kN
Tire model
23.5-25
23.5-25
Max. travel speed
38
32
km/h
Gas cylinder's effective volume
405
405
L


LW500K-LNG is optionally equipped with Weichai WP10NG220E30 engine
Gas Cylinder Parameter
Name
Technical parameters
Unit
Max. operating pressure
1.59
MPa
Total volume/effective wolume
450L/405
L
Loading medium
LNG
Overall dimension(diameter X length)
ø656mm*1960
mm
Heat-insulating mode
High-vacuum multi-layer wrapping
