• Model NO.：ZD160S-3
• Condition：New
• Color：Yellow
• Blade Capacity：4.7cbm
• Engine Model：Wd10g178e25
• Rated Power/Slewing Speed：131tkw,Rpm
• Max. Torque：830,1100tn.M,Rpm
• Min. Fuel Consumption：215g,Kw.H
• Max. Drawbar Pull：152kn
• Ground Pressure：31kpa
• Traveling Speed of Forward：3.8,6.6,10.6tkm,H
• Height of Cab：3140mm
• Ground Contact Length：2935mm
• Height of Blade：1039mm
• Track Center Distance：2300mm
• Height of Grouser：121mm
• Track Shoe Width：950mm
• Max. Lift Height of Dozer：1052mm
• Transport Package：Nude
• Specification：5250*3420*3080 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：84291190
• Production Capacity：1000 Units,Year

 ItemUnitZD160S-3Key    Technical ParameterBlade type-Tilt BladeWorking masskg18100Blade capacitym34.7Engine model-WD10G178E25Rated power/Slewing speedkW/rpm131Max. torqueN.m/rpm830/1100Min. fuel consumptiong/kW.h215Max. Drawbar pullKn152Ground pressurekPa31Gradeability°°30Traveling speed of forwardkm/h3.8/6.6/10.6Traveling speed of Reversekm/h4.9/8.5/13.6Basic    Technical ParameterHeight of cabmm3140Height of ROPSmm3244Ground contact lengthmm2935Height of blademm1039Track center distancemm2300Height of grousermm121Track shoe widthmm950Operating    RangeMax. lift height of dozermm1052Max. drop depthmm450Max. lift height of rippermm--Max. ripping depth of rippermm--Max. tiltmm730
