• Model NO.：Clg4165
• Walking Mode：Wheeled
• Type：Medium-sized Grader
• Rated Power：125kw
• Transport Package：Roro,Bulk,Nude,Container
• Specification：8790*2600*3438mm
• Trademark：Liugong
• Origin：China
• HS Code：84292090
• Production Capacity：100units,Month

Engine DCE.C 6BTAA5.9-C180Rated Power (kW)125(170)@2200Blade Width mm(inches)3960(156)Maximum Speed km/h (mph)38 (23.6)Draw Bar Pull(kN)81.6Operating Weight kg(Lb)15000ENGINE   TRANSMISSIONTransmission Type power shiftTransmission Configuration 6f/3rTorque Converter three-member single turbineMaximum Travel Speed, fwd(km/h)38Maximum Travel Speed, rev(km/h)24.7Number of Speeds, fwd 6Number of Speeds, rev 3 STEERINGSteering Configuration load sensor steering gearSteering Relief Pressure(Mpa)17Minimum Turning Radius(inches)7800(307)Steering Angle ±45°Frame Articulation Angle ±20° TIRESTire Size 17.5-25 PR12/L3HYDRAULIC SYSTEMMain Pump Type gearMain Relief Pressure(Mpa)18Pilot Pump Flow L(Gal)/min126(33)WORKING CAPACITIESMaximum Draw Pull(kN)81.6Cutting Pressure kg(Lb)6800(14991) DIMENSIONSWheelbasemm(inches)6230(245)Overall Lengthmm(inches)8790(346)Overall Height with Cab 3438(135)Overall Widthmm(inches)2600(102)Clearance under Front Axlemm(inches)645(25)Moldboard Standard Lengthmm(inches)3960(156)Moldboard Standard Thicknessmm(inches)19(0.7)Moldboard Standard Heightmm(inches)610(24)OPERATING WEIGHTSOperating Weight kg(Lb)13900(30644)On Front Wheelskg(Lb)3960(8730)On Rear Wheels kg(Lb)9940(21914)
