Good Price Shantui Digging Macinery 6ton Se60 Small Excavator
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Provided
- Warranty：1 Year
- Type：Crawler Excavator
- Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket：Grab Shovel
- Transmission：Hydraulic Transmission
Base Info
- Model NO.：SE60
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
- Size：Small-Scale
- Certification：CE, ISO9001: 2000
- Condition：New
- Transport Package：Nude Packing
- Specification：6T
- Trademark：shantui
- Origin：China
- HS Code：8429521200
- Production Capacity：10000,Months
Description
GINEModel Kubote pV2607T Type 4-cylinder in line, turbocharging Quantity of cylinders 4 Bore x stroke 87 x 110 mm Displacement 2.615 L Power output 36 kW/2000 rpm Maximum torque - HYDRAULIC SYSTEM Pump Imported Type Variable piston pump Maximum discharge flow 144 L/min Control circuit 3.5 MPa Travel circuit 24.5 MPa Swing circuit 21.6 MPa TRAVEL SYSTEM Travel motor Variable axial piston Travel brakes Lubricated double-disc Parking brake Pressure release Travel shoes 2 x 40 Travel speed 2.7/4.5 km/h Drawbar pulling force 50 kN Gradeability 70% Minimum ground clearance 300 mm OIL CAPACITY Fuel tank 95 L Cooling system 8.5 L Engine oil 9 L Hydraulic oil tank 74 L System capacity 120 L SWING SYSTEM OIL CAPACITY Brake Pressure Release Mechanical Braking Swing speed 11 rpm Tail swing radius 1655 mm Arm digging force 32.3 KN Bucket digging force 48 KN BUCKET Bucket capacity Backhoe bucket 0.22 m3 (SAE) Number of bucket teeth 5 Bucket width 760 mm Arm length 1.60 m Maximum digging reach/Maximum digging reach at ground level 6.2 m/6.06 m Maximum digging depth/height 3.85 m/5.785 m Maximum dumping height 4.075 m Minimum swing radius 2.395 m
