Crawler Excavator 37ton Se370LC with Attachment Cheap Price for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- Type:Crawler Excavator
- Usage:Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
- Bucket:Grab Shovel
- Transmission:Hydraulic Transmission
- Drive Type:Internal Combustion Drive
- Bucket Capacity:1.8m3
Base Info
- Model NO.:SE370LC
- Size:Medium-Sized
- Certification:CE, ISO9001: 2000
- Condition:New
- Trademark:SHANTUI
- Origin:China
Description
Basic Info.
Model NO. SE370LC Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Trademark SHANTUI Origin ChinaProduct Description
Crawler Excavator 37Ton SE370LC with Attachment Cheap Price for SaleHigh-end system configuration
1. World's leading high-adaptability turbocharged engine
2. The world's first-class hydraulic configuration features high working pressure and low pressure loss.
Enhanced working device1. The design of structural parts is comprehensive optimized and the critical load-carrying locations are reinforced to resist against severe working conditions.
2. The baseplates, side plates, and reinforcement plates of bucket are made of high-strength wear-resistant material to improve the durability of bucket.
3. The booms, bucket arms, and buckets of diversified specifications can be combined easily to adapt to diversified working conditions.
Drive sprockets, idlers, track rollers, carrier rollers, and tracks1. Decades of R&D and manufacturing experiences of drive sprockets, idlers, track rollers, carrier rollers, and tracks and world's leading technologies
2. The world's sophisticated forging and heat treatment processes guarantee stable and reliable quality.
Intelligent electronic control and optimal power control1. The intelligent control system realizes high match between power system and hydraulic system to improve the working efficiency and reduce the fuel consumption.
2.The man-machine friendly new generation intelligent electronic control system enables you to master all working status of your machine.
3. Four preset working modes of P (Heavy-Load), E (Economic), A (Automatic), and B (Breaking Hammer) feature easy switchover.
Comparative item | SE370LC (Standard version) |
Overall dimensions | |
Overall length (mm) | 11220 |
Ground length (During transport) (mm) | 6040 |
Overall height (To the top of boom) (mm) | 3520 |
Overall width (mm) | 3200 |
Overall height (To top of cab) (mm) | 3290 |
Ground clearance of counterweight (mm) | 1340 |
Minimum ground clearance (mm) | 565 |
Tail turning radius (mm) | 3520 |
Track length (mm) | 5045 |
Track gauge (mm) | 2600 |
Track width (mm) | 3200 |
Standard track shoe width (mm) | 600 |
Turntable width (mm) | 3190 |
Distance from slewing center to tail (mm) | 3465 |
Working range | |
Maximum digging height (mm) | 10110 |
Maximum dumping height (mm) | 7060 |
Maximum digging depth (mm) | 7365 |
Maximum vertical digging depth (mm) | 5290 |
Maximum digging distance (mm) | 11150 |
Maximum digging distance at ground level (mm) | 10945 |
Working device minimum turning radius (mm) | 4335 |
Maximum lifting height of bulldozer blade (mm) | - |
Maximum digging depth of bulldozer blade (mm) | - |
Engine | |
Model | QSL9 |
Type | Inline 6-cylinder, high pressure common rail, and water-cooled and turbocharged |
Displacement (L) | 8.9 |
Rated power (kW/rpm) | 214/2100 |
Hydraulic system | |
Type of hydraulic pump | Duplex axial variable displacement plunger pump |
Rated working flow (L/min) | 2x300 |
Bucket | |
Bucket capacity (m³) | 1.8 |
Swing system | |
Maximum swing speed (r/min) | 10.5 |
Brake type | Mechanically applied and pressure released |
Digging force | |
Bucket arm digging force (KN) | 174 |
Bucket digging force (KN) | 254 |
Operating weight and ground pressure | |
Operating weight (kg) | 36800 |
Ground pressure (kPa) | 68.3 |
Traveling system | |
Traveling motor | Axial variable displacement plunger motor |
Traveling speed (km/h) | 3.0/4.9 |
Traction force (KN) | 315 |
Gradeability | 70%(35°) |
Tank capacity | |
Fuel tank capacity (L) | 620 |
Cooling system (L) | 30 |
Engine oil capacity (L) | 24 |
Hydraulic oil tank/system capacity (L) | 300/420 |
