• Model NO.：ROADY RD90
• Vibrating Amplitude：1.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Orange
• Cold Aggregate Supply System：13.5kw
• Drying Drum：74kw
• Filler Supply System：11kw
• Transport Package：Nude Packing
• Specification：CE
• Trademark：ROADY
• Origin：Henan, China
• HS Code：84743200
• Production Capacity：10set,Months

No.
 Parts NameParts total power
(KW)Remark
 1Cold aggregate supply system13.5 2The tilted belt feeding conveyer5.5 3Drying drum74 4Oil burning system 96.5 5Hotaggregate elevator15 6Bag dust catcher system144.12 7Mixer tower assemblyvibrating screen11 Mixer74 Asphalt spraying system15 8Filler supply system8 9Pneumatic system11 10Asphalt supply system32.95 The plant total installed power511.57kW Features of Plant Spare Parts Mixing Paddle Tip for RD60 RD90, RD175 Asphalt Mixing Plant etc.
1. The mixer use European technology; big obliquity, strong screw flow, solid three- dimensional compulsory mixing, which will form well boiling layer and consequently achieve well-proportioned mixing during a short time.
2. Asphalt weighing and spraying device use high-speed flux asphalt pump to realize high-pressure shower spraying asphalt, making hot aggregate, filler and asphalt mixed more quickly, equably; shorten the mixing time and enhance the ourput.
3. Vibrating screen use whole airproof vibrating screen whose eccentricity shaft is placed above and its swing range can be regulated. This can realize convenient maintenance.
4. The hot aggregate elevator is with our patent structure( patent No.: 200520128222.8). This part is for double-row double-ear chains, guide sliding wearable material hopper elevating, composite discharging the material with reliable performance.
5.Cold aggregate supply system use Modularize design, convenient transportation and installation and can adjust cold aggregate feeding position; use frequency conversion timing motor for feeding, react sensitively; adjust feeding exactly;
6. Filtering system use two-stage whole dust filtering project, efficiently control dust to grade;
use imported filtering bag, waterproof, oil-proof, well heat-resistant, which efficiently protract the using life.
7.Electric control system use  International famous brand and global  high quality electric control parts to isnure the capacity of the equipment;With fault-detecting and diagnosis alarming ability, convenient for saving the directions for material supplying proportion and printing report forms;
8.Drying drum:The material-raising blades design is reasonable and the burning area structure is with patent technology (patent No.: 200520031574), which makes cold aggregate mix more equably, and with high heat efficiency;
