• Certification：CE
• Condition：New
• Product Name：Road Making Machine
• Application：City Road Edge Line
• Line Types：Flat Line
• Mark Width：100-450 ( Adjustable)
• Name：Road Line Making Machine
• Spray Gun：Double
• Engine：Gasoline Engine
• Marking Thickness：1.5-2.5mm
• Transport Package：Wooden Case
• Specification：113*82*88cm
• Trademark：YUGONG
• Origin：China
• HS Code：8479109000
• Production Capacity：1000sets,Month

Technical parameter

Single gun

Double gun

Model

YG-6L

YG-8L

Motor power

4.3HP

7HP

Unloading flow

6L/min

8L/min

Max output pressure

25mpa

30mpa

High pressure pipe strength

35mpa

40mpa

High pressure pipe length

6*10m

6*2m

10*10m

Max spray width

200mm

450mm

Weight

72kg

128kg

Product features

a. High spray efficiency. Spraying efficiency up to 200-500 square meters per hour, is more than 10 times the construction of transmission drum.

b. excellent surface quality. Spray coating formation, smooth, dense, brushless marks, rolling marks and particles.

c. to extend the use of the coating. High-pressure airless spray paint particles can penetrate the ground clearance, the film and the ground to form a mechanical bite, enhance paint adhesion, extend the service life.

d. save paint. Airless spray coating is easy to get a thickness of 30um, the relative savings of 20-30% paint.

Product Overviews

Q1: How long is your delivery time?
A1: It is according to the model and quantity.
     Generally it is 3-5 days if the machines are in stock.
     It will be 15-30 days if you want to customize the machines.

Q2: Do you provide samples? Is it free or extra?
A2: Yes, we could offer you the sample machine.
      But it's not free. You need to pay for the sample and the cost of freight.

Q3: What is your terms of payment?
A3: We accept T/T, Western Union, Money Gram, Paypal, Alibaba   Escrow etc.
      30% T/T in advance, balance before shipment.
