Famous Brand Large Bulldozer SD60-C5 with Undercarriage Parts
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：1 Year
- Warranty：1 Year
- Type：Special Type
- Transmission：Power Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
Base Info
- Model NO.：SD60-C5
- Engine Power：>515kw
- Certification：CE
- Condition：New
- Color：Yellow
- Operating Weight (Kg)：70630
- Transport Package：Cartons
- Trademark：shantui
- Origin：China
- HS Code：8429521200
- Production Capacity：500000
Description
Basic Info.
Model NO. SD60-C5 Engine Power >515kw Certification CE Condition New Color Yellow Operating Weight (Kg) 70630 Transport Package Cartons Trademark shantui Origin China HS Code 8429521200 Production Capacity 500000Product Description
Famous Brand Large Bulldozer SD60-C5 With Undercarriage Parts Sprocket Segment From China
The long life design ensures high firmness and durability.
* Boat type frame of high carrying capacity: The boat type frame structure and the cast and welded rear axle feature high carrying capacity, high resistance against impact and bending moment, less welding, high strength, high reliability, and safer internal parts.
* New track roller frame and final drive of higher durability: The planetary final drive features small volume, high carrying capacity, and high plane installation strength. The integral track roller frame features high durability, high resistance against mud accumulation and traveling wear, and long life.
* Double drive shock-absorbing structure of higher durability: The newly added shock absorber assembly absorbs the impact load to protect the drive system. The drive assembly installation adopts semi-suspension elastic shock absorber to isolate the transmission of impact and double the comprehensive life.
* Wearing parts of higher wear resistance: The wheel train are made of high-strength wear-resistant materials, with the overall quenched wearing layer thickness 2 times of that of domestic competing products and the cutting edges and end bits thicker by >20% than those of domestic competing products.
| Parameter name | SD60-C5 Standard version |
| Performance parameters | |
| Operating weight (Kg) | 70630 |
| Ground pressure (kPa) | 130.2 |
| Engine | |
| Engine model | QSK19 |
| Rated power/rated speed (kW/rpm) | 450/1800 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 10390*4690*4370 |
| Driving performance | |
| Forward speed (km/h) | F1:0-3.8 F2:0-6.8 F3:0-11.8 |
| Reversing speed (km/h) | R1:0-5.1 R2:0-9.2 R3:0-15.8 |
| Chassis System | |
| Center distance of track (mm) | 2500 |
| Width of track shoes (mm) | 610 (Optional 710/810) |
| Ground length(mm) | 3840 |
| Tank capacity | |
| Fuel tank (L) | 1150 |
| Working device | |
| Blade type | Semi-U blade |
| Digging depth (mm) | 715 |
| Ripper type | Single-shank |
| Ripping depth (mm) | 1435 |
