• Model NO.：XE150WD
• Drive Type：Internal Combustion Drive
• Bucket Capacity：0.1~0.5m³
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Excavator：Wheel Excavator
• Operation Weight：15318 Kg
• Engine：Qsb4.5
• Rated Power：104 Kw
• Max. Torque：586 N.M
• Max. Traction：136 Kn
• Travel Speed：30,11 Km,H
• Chassis Width：2495 mm
• Max Digging Radius：8296 mm
• Max Ground Reach：8085 mm
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：ORIEMAC
• Origin：China(Mainland), Jiangsu
• HS Code：84295212
• Production Capacity：1500 Units, Year

Item
Unit
XE150WD
Operation Weight
kg
15318
Bucket Capacity
m3
0.58
Engine
Model
--
QSB4.5
Rated Power
kW/ r/min
104/2000
Max Torque
N.m
586
Displacement
L
4.5
Fuel Tank
L
250
Hydraulic system
Main Pump/Pilot Pump
--
2
Performance
Rated Flow
L/min
2×160
Working Pressure
MPa
31.4/34.3
Hydraulic oil Tank
L
220
Slewing Speed
r/min
13.7
Bucket Digging Force
kN
90
Rod Digging Force
kN
65
Max Traction
kN
136
Travel Speed
km/h
30/11
Grade Ability
%
70
Dimension
Length
mm
6482
Width
mm
2552
Cabin Height
mm
3158
Chassis Width
mm
2495
Blade(w/h)
mm
2495×564
Max Scope
Max Digging Radius
mm
8296
Max Ground Reach
mm
8085
Max Digging Height
mm
9150
Max Dumping Height
mm
6684
Max Digging Depth
mm
5040
8 Inch plane digging depth
mm
4825
Blade Max Lifting Height
mm
515
 If you need more details about our excavator and parts,

Please feel free to contact me, thank you !
