• Model NO.：Howo
• Type：Medium-sized Loader
• Transport Package：Nude Packing
• Specification：9.166*3.22*3.566 mm
• Trademark：SEM
• Origin：China

Main SpecificationsRated Loadkg6 000Operating Weight with Standard Bucketkg20 000Bucket Capacitym³3.3-5.5Wheel Basemm3 350Overall Dimension (outside of tire)mm8 414X3 370X3 458Operating SpecificationsBreakout Force (GRD)kN183Dump Clearancemm3 048Articulated Angle°38±1TransmissionTransmission Type Countershat, power shiftTransmission Gears F4/R4Torque Converter Type Single stage 3 elementsMaker & Type TR200Forward I/ Reverse Ikm/h7.4/7.4Forward II/ Reverse IIkm/h14/14Forward III/ Reverse IIIkm/h22/22Forward IV/ Reverse IVkm/h38/38AxleMain Drive Type Spiral bevel gear, single stageFinal Drive Reduction Type Planetary type, single stageRear - Oscillating +/-°±11EngineModel WD10G240Rated PowerkW178Rated Speedr/min2 000DisplacementL9.726Implement HydraulicImplement System Type Single load sensing flow sharing systemBoom Raise Times5.3Hydraulic Cycle Time (rated payload)s9.7System Presure SettingMpa18Brake SystemService Brake Dry & caliper, air to oil controlParking Brake Drum type shoe brake,spring applied & oil releasedSteering SystemSystem Type Flow amplifyingSteering Pump Type Piston pumpSystem Presure SettingMpa18Steering Angle (L/R)°38±1TiresSize 23.5-25Type BiasLayer 20Textured Type L3/E3

Our company

Relevant Products
1.Water Truck 2.Insulated Truck and Milk Truck 3.Sewage Suction Truck
4.Garbage Truck 5. High-altitude Operation Truck/Truck with Crane
6.Fuel Truck 7.Chemical Liquid Truck 8.Bulk Cement Truck
9. Concrete Mixer Truck 10.Tractor 11.Semi-Trailer
12. Fire Fighting Truck 13.Dump Truck 14.Van Truck/Refrigerated Truck/Refrigeration Truck
15.Wrecker/Tow Truck 16.Flatbed Truck/Low Bed Truck 17.Sweeper Truck
18. High Pressure Cleaning Truck 19.Liquefied Gas Transport Truck 20.Pressure Vessel

Certificates


Heavy Trucks on board for shipping



Prouducts Quality
1.Quality is life and our company is confident in the superior quality of our products and is the most effective salesman.
2. Our company has advanced production management and research and development technology, and continues to carry out technical innovation.
3. Our company introduced automatic integrated molding production equipment, which greatly reduced production process and ensured product quality stability.
4. Our company has its own set of testing methods and standards.

About Us

1 Factory price, more competitive than agent price.
2 Quality: With SINOTRUK group inspection system, a series inspections are well done before the exportation.
3 Warranty: One year or 100 000k which comes to the first for the engine, gear box, and axles.
4 After-sales: Professional after-sales team sovle your difficult or special questions within 3 working days or 5 working days, and all spare parts are available for your urgent use.
5 Transportation: Professional logistics team work with international shipping company for your truck shipment successfuly.
