• Model NO.：955t
• Type：Medium-sized Loader
• Transport Package：Nude Package
• Specification：6920*2305*3150mm
• Production Capacity：3000

Overall Dimension1Length(with bucket on ground)6863(mm)2Width(to outside of wheels)2305mm)3Bucket width2460(mm)4Height(To the top of the cab)3095(mm)5Wheel base2750(mm)6Tread1855(mm)7Min. ground clearance370(mm)Main Technical Specification1Rated load3000(Kg)2Operating weight10200KG3Rated bucket capacity1.7(m3)4Max. breakout force96kN5Max. dump clearance2850(mm)6Dump reach1030(mm)7Dump angle at any position ≥4508Min. turning radius (1) Outside of bucket 5600(mm) (2) Outside of rear wheel5205(mm)9Pivot angle frame 38+1010Oscillating angle of rear axle+11o11Lifting time of bucket≤5.1(sec.)12Lowering time of bucket≤3.0(sec.)13Dumping time≤1.1(sec.)14Traveling speed(Km/h),3 forward and 3 reverse                                                     (1) 1st gear forward7.3 (2) 2nd gear forward15.7 (3) 3rd gear forward35
