China Top Brand Gr135 11ton Road Machinery Small Motor Grader
Shanghai Super-Above Industry Holdings Co., Ltd.- Condition：New
- Application：Railway, Mine, Farmland, Highway
Base Info
- Model NO.：GR135 motor grader
- Transmission：Hydraulic - Mechanical
- Walking Mode：Wheeled
- Type：Small Grader
- After-Sales Service Provided：Overseas Service
- Drive Type：Rear-Axle Drive
- Engine Model：6bt5.9-C130-II
- Rated Power/Speed：97(2200)Kw(R,Min)
- Dimension：8015X2380X3050mm
- Operating Weight：11000kg
- Max. Gradeability：20%
- Tire Inflation Pressure：300kpa
- Working Hydraulic Pressure：16MPa
- Transmission Pressure：1.3~1.8MPa
- Tractive Force：61.3kn
- Maximum Lift Above Ground：410mm
- Maximum Depth of Cutting：515mm
- Moldboard Width X Height：3048X610mm
- Fuel Tank：260L
- Transport Package：Naked in Container
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8429209000
- Production Capacity：5000PCS,Year
