Automatic Plastering Wall Plaster Rendering Render Machine
Zhengzhou Runxiang Machinery Equipment Co., Ltd.- Type：Plaster Machine
- Shotcrete Type：Wet
- Machining Process：Hydraulic
- Structure：Spiral Type
- Productivity：240m²,h
- Feeding Height：5m
Base Info
- Model NO.：GMGH series
- Vibrating Amplitude：2.4mm
- Certification：ISO9001: 2000, CE
- Condition：New
- Color：Blue
- Capacity：100sets Per Month
- Key Word 1：Plaster Machine
- Key Word 2：Render Machine
- Key Word 3：Wall Plaster Machine
- Key Word 4：Plastering Machine
- Transport Package：Export Wooden Cases
- Specification：ce co ccc
- Trademark：GMEC
- Origin：Zhengzhou
- HS Code：84283200
- Production Capacity：100 Sets Per Month
Description
MODEL GMEH-800-R GMEH-1000-R GMEH-800-G GMEH-1000-G Rendering height m Standard 3.5
(Up to 5) Standard 3.5
(Up to 5) Standard
3.5 (Up to 5) Standard 3.5
(Up to 5) Rendering width mm 800 1000 800 1000 Rendering thickness mm 2-30 2-30 2-30 2-30 Rendering speed m2/h 30-60 40-80 30-60 40-80 Voltage V 380/220 (Customized) 380/220
(Customized) 380/220
(Customized) 380/220
(Customized) Lifting mode - By steel wire rope By steel wire rope By gear rack By gear rack Main motor power Kw 1.5 1.5 1.5 1.5 Vibrating motor power Kw 2*0.03 3*0.03 2*0.03 3*0.03 Parts weight Kg 50 60 80 90 Machine weight Kg 80 100 150 170 Outer dimension mm 1000×830×680 1150×830×680 1000×830×680 1150×830×680
Brick Wall, Block Wall, Cement Wall, Internal Wall, House, Building, Skyscraper, Villa, Etc.
4. Applied materials
Cement, Gypsum, Lime, Ready Mix, Perlite, General Mortar, Insulation Mortar, Clay Mortar Or similar materials.
5. Comparison between machine and manual rendering.
6.Packaging & Shipping
Features
1. Our machine utilize the conveyor taking mortar forwardly and upwardly,It can plaster to the roof by all means(no leave 1mm).In this aspect our machine is unique.The conveyor can take mortar or stop in any position by hand control.
2. The spatula can change the angle at will,plastering the wall by rising large angle,sharpening and pressing by angle decline,thus guaranteed zero vertical error and plastering to the roof.
3. The hydraulic telescopic rod can make the machine installation in 10 second and the chassis is not stress.When you want to move the machine you just can release the rod as moving jack. The main rod declined by gravitation,the bottom life automatically.This kind of installation is the most fast and stable one.
4. The width of spatula is designed according the width of the door,The machine can go into the room freely.It can reach the inside corner and the exposed corner.
5. There are two min-vibrators after the spatula,thus you need not to worry about Hollowing and adhesion.
6. Our machine adopted the universal wheel after sealing and it can easily move to any place you like.
7. This machine is totally artificially designed.
8. The capacity is as 15 professional plasterers.
9. Saving more than 20% raw material (cement &sand)
10. Hydraulic lifting methods to improve the stability of the machine.
(Up to 5)
(Up to 5)
3.5 (Up to 5)
(Up to 5)
(Customized)
(Customized)
(Customized)
Brick Wall, Block Wall, Cement Wall, Internal Wall, House, Building, Skyscraper, Villa, Etc.
4. Applied materials
Cement, Gypsum, Lime, Ready Mix, Perlite, General Mortar, Insulation Mortar, Clay Mortar Or similar materials.
5. Comparison between machine and manual rendering.
| Comparison | Rendering Machine | Manual Rendering |
| Speed/8h | 500-750m2 | less than 50m2 |
| Finishing | smooth & flat with mirror finishing. | always reveal crack, bubbles, etc. |
| Coating | Once coating while render up and smooth down | several times coating by numberless trowels |
| Procedures | Automatic by machine | adjust leveling by square bar again and again |
| Extra supporting | electricity | scaffolding, mop, trowel, square bar, lots of extra tools |
| Labor Intensity | two workers. | a lot more. Hard work. |
| Time Consumption | saving 70% - 80% time | long time work |
6.Packaging & Shipping
| PACKAGE | In two seaworthy plywood boxes |
| CONTAINER NEEDED | One 20'GP for 25 units or by LCL |
Features
1. Our machine utilize the conveyor taking mortar forwardly and upwardly,It can plaster to the roof by all means(no leave 1mm).In this aspect our machine is unique.The conveyor can take mortar or stop in any position by hand control.
2. The spatula can change the angle at will,plastering the wall by rising large angle,sharpening and pressing by angle decline,thus guaranteed zero vertical error and plastering to the roof.
3. The hydraulic telescopic rod can make the machine installation in 10 second and the chassis is not stress.When you want to move the machine you just can release the rod as moving jack. The main rod declined by gravitation,the bottom life automatically.This kind of installation is the most fast and stable one.
4. The width of spatula is designed according the width of the door,The machine can go into the room freely.It can reach the inside corner and the exposed corner.
5. There are two min-vibrators after the spatula,thus you need not to worry about Hollowing and adhesion.
6. Our machine adopted the universal wheel after sealing and it can easily move to any place you like.
7. This machine is totally artificially designed.
8. The capacity is as 15 professional plasterers.
9. Saving more than 20% raw material (cement &sand)
10. Hydraulic lifting methods to improve the stability of the machine.
