Chenggong Earthmoving Machinery 5 Ton Mini Track Compact Wheel Loader Cg955
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Certification：TUV, UL, ISO, RoHS, CE, ISO9001: 2000, GOST
- Condition：New
- Rated Load：5ton
- Transmission：Hydraulic Transmission
- Load and Unload Mode：Front Discharge
- Walking Mode：Wheeled
Base Info
- Model NO.：CG955
- Type：Medium-sized Loader
- Bucket Capacity：2.5cbm
- Operating Weight：17.4 Ton
- Engine：Weichai
- Usage：Universal Type
- Scraper Type：Tractor-Scraper
- Load and Unload Method：Front Discharge
- Engine Power：162 Kw
- Color：Yellow
- Warranty：1 Year
- Tire：23.5-25
- Transport Package：40hq
- Specification：ISO, CE
- Trademark：Chenggong
- Origin：Jiangsu Xuzhou
- HS Code：84295100
- Production Capacity：1000sets,Month
Description
Main Specifications
CG955
Engine Model
Shangchai SC11CB220G2B1
Rated Power/Rated Revolution
(kw/rpm)
162/2200
(hp/rpm)
217.2/2200
Rated Load Weight (kg/lb)
5000/11023.1
Max.Dump Clearance (45°Discharge) (mm/ft′in″)
3196/10′5″
Dump Reach (Max.Dump Clearance) (mm/ft′in″)
1033/3′4″
Max. Forward Speed (km/h/mph)
36/22.4
Min. Turning Radius (mm/ft′in″)
6900/22′8″
Action Time of Working Device(s)
10.0
Lifting Time of Working Device(s)
6.0
Bucket Capacity (m3 /yd3)
2.5-3.6/3.3-4.7
Breakout Force (kN/kip)
170/38.25
Overall Size(L*W*H) (mm/ft′in″)
8020*3000*3480
26′3″*9′8″*11′4″
Operating Mass (kg/lb)
17400/37478
Wheelbase(mm/ft′in″)
3280/10′8″
