• Vibrating Amplitude：1.6mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Red
• Concrete Slump Range：8~23cm
• Theoretical Pumping Times：24~27min
• Theoretical Output：150m3,H
• Reach Height：38m
• Emission Standard：Eruo III
• Max. Speed：85km,H
• Wheelbase：4600+1350mm
• Hopper Capacity：550L
• Distribution Valve：S Valve
• Hydraulic Oil Cooling：Wind Cooling
• Recommended Concrete Slump：12-23m
• Pipe Diameter：125mm
• Transport Package：Nude
• Specification：36350kg
• Trademark：ZOOMLION
• Origin：Hunan, China
• Production Capacity：100units,Week

Dimension

10690x2500x3760mm

Total weight

18000kg

chassis

Model

SYM1180T1E

 Engine

J08E-WY

Power

199kw

Emission standard

Euro 5

Maximum speed

90km/h

Pumping system

Output

108m³/h

Pumping pressure

6.6Mpa

Pumping frequency

25times/min

Oil pressure

32Mpa

Filling height

1600mm

Placing boom

Height

30.1m

Depth

15.2m

Minimum expansion height

9.6m

Rotation angle

360°

First arm extension angle

89°

Second arm extension angle

180°

Third arm extension angle

245°

Forth arm extension angle

230°

Length of first arm

7676mm

Length of second arm

6090mm

Length of third arm

6100mm

Length of forth arm

6635mm

Extension height of front leg

5850mm

Extension height of rear leg

5000mm
