• Model NO.：HPY9120
• Engine：Cummins or Yuchai
• Turning Angle：360 Degree
• Usage：Universal Type
• Scraper Type：Tractor-Scraper
• Load and Unload Method：Front Discharge
• Engine Power：60-100kw
• Color：According to Buyers
• Transport Package：Nude
• Specification：ISO, SGS
• Trademark：Haiqin
• Origin：Shandong, China
• HS Code：84292090
• Production Capacity：8000 Units , Year

Basic Info.

Model NO. HPY9120 Engine Cummins or Yuchai Turning Angle 360 Degree Usage Universal Type Scraper Type Tractor-Scraper Load and Unload Method Front Discharge Engine Power 60-100kw Color According to Buyers Transport Package Nude Specification ISO, SGS Trademark Haiqin Origin Shandong, China HS Code 84292090 Production Capacity 8000 Units / Year

Product Description

Features :
Choose China Yuchai supercharged high performance engine is selected, with large torque and low noise. Perfect match with double high base gearbox, best performance and fuel efficiency in advance, energy saving and high efficiency.
The hydraulic locking cylinder is used for positioning to ensure accuracy and convenient operation. The hydraulic oil pipe is built-in to effectively prevent the aging and wear of the oil pipe.

Specifications :
Overall operation quality:   6110kg
Front axle maximum swing angle :  + 16 degrees
Maximum angle of front wheel:   + 45 degrees
Frame twist angle:   + 23 degrees
Cutter head diameter (mm):  1250mm
Blade specification (L x W x H):  3000x480x18
Blade rotation angle:  360 degrees
Blade ground clearance:  450mm
Blade cutting depth:  260mm
Blade tilt angle:  47 ° forward / 5 ° backward
Blade slide range:  550mm left / 550mm right
