• Model NO.：XE370CA
• Size：Large-Scale
• Certification：ISO9001: 2000
• Condition：New
• Rated Power：190kw
• Engine Model：Isuzu
• Operating Weight：25500kg
• Maximum Digging Height：9662mm
• Specification：10160*3190*3000mm
• Trademark：XCMG
• Origin：Jiangsu
• Production Capacity：30

  UnitParametersModelOperating weightkg25500Bucket capacitym³1.05-1.25EngineEngine model/ISUZU CC-68G1TRP-05Direct injection/√4×strokes/√Water cooling/√Turbocharging/√A/A Air-air intercool/√Cylinders/6Output power of engineKw/rpm135.2/2150Max.torque/engineN.m/rpm637/1800DisplacementL6.494Mian pertormanceTravel speedkm/h5.9/4.0Slewing speedr/min11.3Gradient capability°≤35°Ground pressurekPa50.1Digging capacity of tcuketkN179Digging capacity of tcuket rodkN125Max.tractionkN194Hydraulic systemMain pump/Tow plunger pumpsRated flow of main pumpL/min2×256Pressure of main safety valveMpa34.3/37Pressure of traveling systemMpa34.3Pressure of swing systemMpa28Pressure of pilot systemMpa3.9Oil volumeFuel tank capacityL400Hydraulic tank capacityL240Engine oil volumL25Apperance sizeA Total lengthmm10160B Total widthmm3190C Total heigthmm3000D Width of rotary tablemm2830E Length of trackmm4640F Total width of chassismm3190G Width of trackmm600H Wheelbase of trackmm3742I Track gaugemm2590J Counterweight ground clearancemm1100K Min.ground clearancemm485L Min.tail swing radiusmm2985Working scopeA Max.digging heightmm9662B Max.unloading heightmm6810C Max.digging depthmm6895D Digging depth at the range of 8 feets horizontallymm6750E Max.vertical digging depthmm5480F Max.digging radiusmm10240G Max.swing heightmm3850Standard configurationBoom lengthmm6000Length of bucket rodmm2960Bucket capacitym³1.2Optional counfigurationLength of bucket rodmm2500Bucket capacitym³1.25Rock bucket  1.05Earthmovingbucket







XCMG is a construction machinery manufacturer with over 70 years of experience. Over the years, we have grown to become the world's most comprehensive construction machinery manufacturer and influential multinational company. In 2019, we rank No.1 in China and No. 5 in global heavy equipment industry.XCMG's construction machinery covers an astonishing range of equipment, including cranes, earth-moving  machinery, road machinery, excavators, concrete machinery, mining machinery, piling machinery, lumber machinery, fire-fighting machinery, heavy trucks, sanitation machinery, agricultural machinery, and more. We have the world's most comprehensive product line, and offer customers complete solutions for construction equipment.  Our other businesses include finance, leasing, and remanufacturing.

Competitive Advantage
My company's excavators covers 3.5-900 tons of products, to meet a variety of conditions, with the largest tonnage excavators mature manufacturing technology, scientific research and development process, advanced Research and development technology, and constantly have new products to market, to meet customer use.

XCMG's new-generation intelligent hydraulic excavators are energy-saving, efficient, comfortable and intelligent. The new hydraulic systemprovides good controllability and high efficiency; good working conditionadaptability improves fuel economy;the fan adopts stepless variable speed control, which helps reduce the energy consumption and noise;the 2D slope finishing system provides construction accuracy and efficiency; E-wallensures construction security and quality; the on-line weighing system helps prevent overload and underload in loading operations; easy to operate, and provides strong feeling of human-computer interaction.

XCMG will offer you the high quality products with a low price, quick delivery,and professional after-sale service.
