Motor Graders 12K 16 Ton / 140K 18 Ton

Evangel Industrial (Shanghai) Co., Ltd.
  • Certification：ISO
  • Condition：New
  • Application：Mine
  • Transmission：Hydraulic - Mechanical
  • Walking Mode：Wheeled
  • Type：Medium-sized Grader

Base Info

  • Specification：13300*3490*3450
  • Origin：China

Description

ParametersItemSG21-3Engine  6CTAA8.3-C215Rated power (kW/rpm)160/2200Travel speed (km/h) Forward 10-5.4Forward 20-9.4Forward 30-12.2Forward 40-20.5Forward 50-25.4Forward 60-39.7Reverse 10-5.4Reverse 20-12.2Reverse 30-25.4Dimensions (L×W×H) (mm)9260×2600×3400Minimum turning radius (mm)8200Wheel base (mm)2155Gradeability (°)20Ma×imum traction (KN)90Ma×imum cutting depth (mm)500Operating weight (kg)17000Blade width (mm)3660/3965/4270Blade height (mm)635Blade rotational angle (°)360Ma×imum lifting height (mm)410Blade cutting angle adjustment Range (°)               44-91Min. ground clearance (mm)430Working hydraulic system pressure (MPa)16Brake System Pressure (MPa)10
