• Model NO.：6118E
• Compaction Depth：40cm
• Engine Type：Diesel Engine
• Travel Speed：40cm,s
• Centrifugal Force：300,180 Kn
• Certification：CE, ISO 9001:2000
• Condition：New
• Operating Mass：19000kg
• Transport Package：Nude
• Specification：6450*2340*3150MM
• Trademark：LIUGONG
• Origin：China
• HS Code：8429401100
• Production Capacity：500,Month

Operating Mass

19000 kg

Mass On Vibrating Drum

9500 kg

Mass On Drive Axle

9500 kg

Front Drum Static Linear Load

437 N/cm

Model

Shangchai SC8D180.3G2B1

Emission Regulation

Stage II

Rated Power

132 kW (179 hp) @ 1800 rpm

Vibration Frequency

28 / 33 Hz

Nominal Amplitude

2.0 / 1.3 mm

Centrifugal Force

360/275 kN

Drum Diameter

1600 mm

1st Maximum Speed, fwd

2.7 km/h

2nd Maximum Speed, fwd

5.2 km/h

3rd Maximum Speed, fwd

11 km/h

Theoretical Gradeability

30%

Min. GroundClearance

450 mm

Wheelbase

3230 mm

Min. Outside Turning Radius

7000 mm

Overall Length

6450 mm

Overall Width

2340 mm

Overall Height

3150 mm
