• Model NO.：YCR60
• Motor Power：90kw
• Noise：Without Noise
• Certification：EPA, CE, ISO 9001:2000
• Condition：New
• Power/ Revolution：86kw,2200rpm
• The Maximum out Torque：60kn·m
• Transport Package：Roro
• Specification：7550*4200*19040mm
• Trademark：Yuchai
• Origin：Jiangxu, China
• Production Capacity：1000 Pieces,Per Month

ProjectUnitParameterMax.Drilling Diameter  Uncased
(mm)φ1500Cased(mm)-Max.Drilling Depth(m)56Dimension  Working condition L × W × H
(mm)
7550×4200×19040Transportation condition L × W × H(mm)13150×2960×3140Overall Drilling Weight(t)49Engine  Model
-
 QSB7-C202Rated Power(kW)150/2050Hydraulic System  Working pressure
(MPa)
35Rotary Drive  Max. output torque
(kN.m)
150Rotary speed(r/min)7~33Spin off speed(r/min)-Pull-Down Cylinder  Max.pull-down piston push
(kN)
120Max.pull-down piston pull(kN)160Max.pull-down piston stroke(mm)3500Crowd Winch  Max.pull-down piston push
(kN)
-Max.pull-down piston pull(kN)-Max. pull-down piston stroke(mm)-Main Winch  Max.pulling force
(kN)
160Max. single-rope speed(m/min)72Diameter of the steel wire rope(mm)26Auxiliary Winch  Max. Pulling force
(kN)
50Max. single-rope speed(m/min)60Diameter of the steel wire rope(mm)16Drilling mast  Left/right inclination of mast
(°)
42432Front inclination of mast(°)5Rotary table slewing angle(°)360Traveling  Max. traveling speed
(km/h)
2.5Max.grade ability(%)40Crawler  Track shoe width
(mm)
700Distance between tracks(mm)2960~4200The length of crawler(mm)4310Average ground pressure(kPa)83
