• Model NO.：GR135
• Engine Model：6bt5.9
• Rated Power：100kw
• Operating Weight：11000kg
• Blade Width：3710mm
• Tractive Force：61.3kn
• Working Hydraulic Pressure：16MPa
• Maximum Lift Above Ground：410mm
• Maximum Depth of Cutting：535mm
• Transport Package：1unit, 40hq Container
• Specification：CE, RoHS, SGS, GMP
• Origin：Xuzhou
• HS Code：8429209000
• Production Capacity：500 Units,Month

Basic specification
Engine model6BT5.9Rated power/speed100/2200kw/rpmDimension(LxWxH)8015×2380×3050mmOperating weight(Standard)11000kg
Performance specification
Travelling speed ,forward5,8,13,20,30,42km/hTravelling speed ,reverse5,13,30km/hTractive force(f=0.75)61.3KNMax. gradeability20%Tire inflation pressure300kPaWorking hydraulic pressure16MPaTransmission pressure1.3~1.8MPa
Operating specification
Max. steering angle of front wheels±49°Max. lean angle of front wheels±17°Max. oscillation angle of front axle±15°Max. oscillation angle of balance box16Frame articulation angle±27°Min. turning radius using articulation6.6m
Biade
Maximum lift above ground410mmMaximum depth of cutting535mmMaximum blade position angle90°Blade cutting angle28°-70°Circle reversing rotation360°Moldboard width X height3710×610mm

We supply all kinds of Machinery & Equipment of most Chinese big brands like LIUGONG, SINOTRUK etc to global market with reasonable
price and best service. Most of products are meet with ISO,CE,EPA,GOST standards.
Our advantages are as following:

1. Professionally export construction machinery and spare parts for more than 8 years to over a hundred countries.
2. Experienced in customs clearance in different ports(countries). Clients type has big contractors, tender, private,rental companies, construction companies etc.
3. Quick delivery time and thoughtful services.

Any further questions , please do not hesitate to inform us!
