• Model NO.：FR480E
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Transport Package：Nude Package, Suitable for Shipment
• Specification：12253*3340*3900mm
• Trademark：Oriemac
• Origin：Shandong
• HS Code：87059091
• Production Capacity：1000

Main Parameters12253*3340*3900Operation Weight46000Standard Bucket Capaclity2.1Transport Dimensions(L×W×H)12253*3340*3900Bucket Digging force (kN)290Bucket Rod Digging Force (KN)235Maximum Traction Force (kN)382DeviceHigh-low Speed (Km/h)4.6/2.9Climbing Performance(°)35Total Length of the Crawler Tail Turning Radius (mm)3800Width of the Crawler600Ground Pressure (Kpa)80Turning MechanismTurning Speed (rpm)9.5EngineModelCUMMINS QSM11Type Rated Power/Rotate Speed (KW/rpm)298/2000Rated Torque/Rotate Speed (N.m/rpm) Cylinder Diameter*Stroke (mm)125*147Output Value (L)10.8Fuel Consumption (g/KW.h)216Fuel Tank Capacity (L)670Hydraulic SystemMain Pump Pressure32.4/35.3Main Pump Flow370*2Operating ScopeMaximum Digging Height (mm)10840Maximum Dumping Height (mm)7650Maximum Digging Depth (mm)7765Maximum Digging Radius (mm)11970picture


Packaging & Shipping
