• Model NO.：RP602L
• Certification：ISO9001: 2000, CE
• Condition：New
• Basic Paving Width：2.5m
• Max. Paving Width：6m
• Max. Paving Thickness：380mm
• Engine：Bf4m1013c
• Transport Package：Main Machine Nude, Attached Parts Into Export Case
• Specification：5960kg
• Origin：Jiangsu China
• HS Code：84791021
• Production Capacity：100 Unit Per Month

Basic Info.

Model NO. RP602L Certification ISO9001: 2000, CE Condition New Basic Paving Width 2.5m Max. Paving Width 6m Max. Paving Thickness 380mm Engine Bf4m1013c Transport Package Main Machine Nude, Attached Parts Into Export Case Specification 5960kg Origin Jiangsu China HS Code 84791021 Production Capacity 100 Unit Per Month

Product Description

Microsurfacing Concrete Asphalt Sealer RP603 RP602L Road Slurry Seal Paver
Product description

RP602/RP802 multi-functional paver can be applied to the paving of basic stabilized material and surface material. The machine adopts independent right drive and left drive, micro-computer control, and the telescopic screed with single vibrating tamper (RP802 is equipped with pulse vibration). The material level is controlled by ultrasonic sensing technique, featuring good stability in low-speed paving, even material feeding, high preloading compactness, good pavement evenness, and easy operation. It can absolutely meet the construction requirements.

Parameter

Item	Unit	RP602
Basic paving width	m	2.5
Max. paving width	m	6
Max. paving thickness	mm	380
Paving speed	m/min	0~14
Travel speed	km/h	0~3.0
Theoretical productivity	t/h	400
Hopper capacity	t	13
Gradeability	%	20
Pavement evenness	mm/3m	3
Cross slope error	%	±0.03
Crown adjustment range	%	0~3
Diesel engine model		BF4M1013C
Diesel engine power	kw	118
Diesel engine speed	r/min	2300
Diesel oil tank capacity	L	230
Overall weight	t	15.8~21.5
Dimension	mm	6230×2500×3855
Vibration frequency	Hz	/
Screed heating mode		Electrical heating
Material level control mode		Automatic Control by Ultrasonic Sensor
Automatic Leveling Control		Simulation control

Item	Unit
Screed model	475(RP602)
Type	Vibration, electrical heating
Stretch mode	Hydraulic stretch
Width range	2.5-6.0m
Vibrating tamper rotate speed	0-1500r/min
Vibration frequency	4mm
